Fiber Laser Marking Systems 10W/20W/30W Marking Erea 150/180/220/300mm

Shenzhen Dapeng Laser Technology Co., Ltd.
  • Application：Leather Industry, Domestic, Carpentry, Printing & Packaging, Construction Industry, Molds & Dies, Crafts Industr, Advertising Industry, All Industries
  • Cooling System：Air Cooling
  • Technical Class：Pulse Laser
  • Automatic Grade：Automatic
  • Applicable Material：Metal
  • Type：Oscillating Mirror

Base Info

  • Model NO.：2
  • Laser Classification：Free Electron Laser
  • Engraving Method：Vector Engraving
  • Model No.：Ylp-20
  • Engraving Machine Type：Laser Engraving Machine
  • Laser Type：Fiber Laser
  • Current：AC
  • Usage：Metal, Plastic
  • Control：Automatic
  • Drive Type：Fiber Laser
  • Certification：SGS, Ce
  • Power：10watt, 20watt, 30watt
  • Export Markets：Global
  • Transport Package：Wooden Box
  • Specification：CE, SGS
  • Trademark：DP
  • Origin：Shenzhen, China
  • HS Code：84561000
  • Production Capacity：3000 Sets,Year

Description


Easy to Use Automation FeaturesSharp, High Contrast, Impact FreeHigh Speed Galvo SteeringCompact & Fast Set-Up100,000 Hrs Laser Lifetime2 Year WarrantyTurnkey SystemPermanant MarkingAir Cooled/No Chiller neededTunable Pulse RateNo routine maintenance/No ConsumableDigital I/O for Easy OperationRed Aiming Pointer/No more mistakesSolid Aluminum Top Work Surface & Swing Arm Laptop StandPortable Tabletop Units to Automated Production Systems Available

Specifications:

Model   YLP-F10/20/30Laser Power:10W,20W,30WWavelenth:1064nmStandard Marking Area:100mm*100mmOptional Marking Area:160mm*160mm,200mm*200mmMarking Speed:≤7000mm/sMinimum Line Width0.02mmMinimum letterEnglish: 0.2 x 0.2mmMarking Depth0 ~0.5mmLocation precision≤0.01mmResetting positioning accuracy0.002Beam QualityM2:1.2~1.8Electrical Requirements:Ac220V±10%.50HZ.5AmpCooling modeAir cooledScan HeadHigh Precision Digital Scan HeadUnit Power<0.5kwOperational Temp Range10-40ºCOperational Humidity Range5%-75%, Non-condensingWarranty:1 years on laser sourceDimensions:25*60*80MMNet Weight38KG


Software:
True Type FontsSingle Stroke FontsElliptical TextSequential Serial NumbersCustomizable Auto DatingBarcodesQR Codes and Data MatrixUID WizardLogosPhoto Quality Images - JPG, TIF, GIFCorel Draw, Adobe IllustratorRaster GraphicsVector GraphicsCAD Files


Applications:

We offer Fiber Laser Marking Machine with following applications:
l         Laser marking of metal & non-metal material and products: Stainless steel, gold, silver, copper, aluminium alloy, hardware, tools, acrylic, ceramics, plastics, organics, thermo-elastomer rubbers, paper and others
l         Hall marking on Gold
l         Automotive & Engineering Industries
l         Electronic industry: Capacitor, inductor, PCB, IC, connector, control panel and other  instruments
l         Others: Cosmetics, food package, bottle, gift, advertisement & sign crafts, craft & gift making

We also provides laser sources and spare parts to the laser machine manufacturers in China and surrounding countries.

Materials:
Stainless SteelSteelAluminum, CarbideNickelTitaniumCast IronChromePainted Metal AlloysMulti-Coated MetalsPlastics/RubberBacklit ButtonsPolycarbonatePVCCompositesMany more materials

sample marking but not limit
