• Model NO.：fly laser marking machine
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Marking Speed：>7000mm,S
• Min.Line Width：0.11mm
• Min.Character Size：0.15mm
• Marking Area：110*110mm,150*150mm,300*300mm
• Wavelength：1064nm
• Marking Depth：≤0.2mm
• Transport Package：Wooden Case
• Specification：710*510*710 mm
• Trademark：CNMANLASER
• Origin：Shandong
• HS Code：8456110090
• Production Capacity：5000 Sets,Year

Basic Info.

Model NO. fly laser marking machine Type Optical Fiber Laser Marking Machine Marking Method Scanning Marking Marking Speed >7000mm/S Min.Line Width 0.11mm Min.Character Size 0.15mm Marking Area 110*110mm/150*150mm/300*300mm Wavelength 1064nm Marking Depth ≤0.2mm Transport Package Wooden Case Specification 710*510*710 mm Trademark CNMANLASER Origin Shandong HS Code 8456110090 Production Capacity 5000 Sets/Year

Product Description

Camera Watches Cnc Flying Fiber Laser Marking Machine With Conveyor Belt

     (Model:Man-50)



1. Germany Made Fiber Laser Sources>> A Wide Selectivity of Operating Wavelengths, Ultra-Low Amplitude Noise, High Stability and Ultra-Long Lifetime

   2. Digital Galvanometer Laser Scanning Head with Fast Marking Speed>>Fast Response Ability <0.7ms, High Speed Marking and High Precision.

   3. Focus Mirror>> Singapore famous "Wavelength" brand, Fast speed, high transparent rate

   4. Control System>> EZ-CAD control system with stable performance and high reliability. More than 10,000 sets of equipment are using EZ-CAD control card, shield-utilizing parts of complex functions, ensuring higher stability.

   5. Red Light Pointer>>Adopt red light pointer to show the laser path since laser beam is in-visible.

   6. 3D Working Table>> Made up by Precision Alloy and Imported Precise Beeline Device, can be lifting and shifting from left to right. Easy to adjust the laser focus distance.

   7. Laser Power Supply>> Adopt Taiwan Famous brand, Stable performance, long life span.

   8. Portable Handle>>Easy to held the machine by hand.

   9. Emergency Stop>> Press it when meets error, the machine will stop working immediately to avoid losses.

   10. Key Switch>> Using key swith to control the power of the machine.

   11. Main Switch>> It is designed as a easy button, safe and efficient.
2.
3. 12.Online Flying System and transfer belt>>Include 1.5*0.2*0.8m Conveyor Photoelectric Switch will Induct the Products to Have Dynamic automatic Continuous Marking Improve Production Efficiency to Have Mass Production.

   online flying fiber laser marking machine is widely used for metallel marking , stainless steel marking , nylon marking , ABS / PVC / PC markingplastics marking , rubber marking , resin marking , ceramic marking , etc in foodprinting , medicine printing , soft-drink printing , cigarette code , wines industry ,mineral water , daily cosmetic , wires and cables and all kinds of production line


Shandong Mann Machinery Equipment Co., Ltd. was founded in 2008. Its factory and headquarters are located in Shandong, China. It has 7000 square meters of factory buildings and more than 300 workers. Professional production and export of laser engraving machine, laser cutting machine, laser marking machine, CNC engraving machine and other state-level high-tech enterprises, the company has independent import and export rights, products in the United States market have passed CE, FCC, SGS, IU, FDA certification. We have also achieved tremendous success in the international market. The main foreign markets are more than 30 countries and regions, such as the United States, Germany, Spain, Russia, Singapore and so on. We warmly welcome you to visit our factory.
