• Model NO.：1218 1225
• Laser Technology：Laser Flame Cutting
• Color：Orange and Blue, or Customized
• Software：Zy1610 Laser Control System
• Support Format：Plt,Crd,Ai,Dwg,Dxf,Dst
• Machine Weight：4000kg
• Transport Package：Wooden
• Specification：1220*2440mm, 200~800mm,3000mm
• Trademark：BNT laser
• Origin：Jinan
• HS Code：8456110090
• Production Capacity：20 Pieces,Year

Basic Info.

Model NO. 1218 1225 Laser Technology Laser Flame Cutting Color Orange and Blue, or Customized Software Zy1610 Laser Control System Support Format Plt,Crd,Ai,Dwg,Dxf,Dst Machine Weight 4000kg Transport Package Wooden Specification 1220*2440mm, 200~800mm/3000mm Trademark BNT laser Origin Jinan HS Code 8456110090 Production Capacity 20 Pieces/Year

Product Description

Auto Part Manufacturing 1812 High Power 400W 600W 1000W 1500W CO2 Flat Die Board Machinery Wood Plywood Die Cutting Laser Cut Die Making Machine Price





Machine parameters:

Model No.	BNT-1812-1500W
Power	1500W
The table moving	Gantry construction
Laser output power	High power axial flow CO2 laser source
X-axis travel-length	1300mm
Y-axis travel-length	1800mm
Cutting speed	90-120m/h
Re-Positioning Precision	≤0.02mm
Cutting width kerf	0.45mm, 0.71mm, 1.05/1.07mm at one time (die board)
Controlling system	zhiyuan
Transmission system	Ball screw & Linear guide (TAIWAN)
Driving system	Japan high-precision servo motors
Optical system	US
Moving structure	Gantry
Chiller system	Made in China
Overall dimensions (L x W x H)	3200*2300*1650mm
G. Weight	4000kg
Laser generator gas matched	Mixed gas(99.99%)
Laser cutting thickness	0.1-30mm
Centrifugal blower	1 set

Main Features

- Gantry construction, Cross construction,stable working, small floor space required for machine.

- Laser cutting head coming with automatic touching system, adapt to the jagged materials and keep cutting kerf precision.

- Adopt Panasonic Servo Drive and Motor system, Taiwan HIWIN precision linear guide rail to keep high precision cutting.

- Highly effective smoke-exhausting system coming with optimized dust collector device to create healthy environment for operator.

- Automatic gas control system to ensure low energy consumption operation power consumption and gas consumption.

- Software is easy to operate and simple, easy to understand

Characters

1,Self Develop Laser Source And Machine Structure The whole machine is stable and reliable.

2,10 years of professional experience in the production of large laser equipment, providing sound technology, timely service and long-term protection.

3,Using a unique hybrid laser gas and standby mode, the cost is 2/3 of similar products, energy saving.


The core configuration:

Lens :

1,Self Develop Laser Source And Machine Structure The whole machine is stable and reliable.

2,10 years of professional experience in the production of large laser equipment, providing sound technology, timely service and long-term protection.

3,Using a unique hybrid laser gas and standby mode, the cost is 2/3 of similar products, energy saving.

Samples:



Applicable Industries:

Can be widely used in Printing,Packing,Mould Making,Advertising Signs,Metal Plates,Light-fixture,Hardware,Electrical Components,Craftworks,...etc. Industries.

Suitable Materials:

Plywood,Acrylic Board,MDF Board,Iron Board,Steel Board,Stainless Steel Board,Aluminum Board,Copper Board,...etc.

Our company:




Our company is a light, mechanical and electrical integration of high-tech enterprises, specializing in high-power lasers, laser cutting equipment research and development, production and sales of knowledge-intensive enterprises; It has a skilled costume team, experienced training and after-sales team, etc. This not only guarantees the advanced nature, stability and reliability of the company's products, but also lays a solid foundation for the production and development of the enterprise.

Mainly involved in laser knife moulding industry, plastic plate, box board, size plate, electronic board, acrylic board, rubber plate, etc.

Products cover cutting, carving, marking and other processing fields, power range from dozens of watts to several kilowatts, products and services throughout the printing crosscutting board, thin metal cutting, solar photovoltaic, advertising decoration, aerospace, electronics, Home appliances and other industries.

Customers:

After sales service:

1.English speaking engineer is available for installation and training under buy's cost around 5days.

2.English software, installation and related training instructions and videos are available for end-users.

3.In case of any problems or questions about laser technology you can always refer to BNT Laser.

4.With our customer-orientated service support, maintenance and repair costs will be kept low.

5.One year guarantee for machine is promised.
