• Model NO.：PEDB-400D
• Laser Wavelength：Fiber Laser
• Laser Classification：Solid Laser
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Cooling Way：Air Cooling
• Lifetime：10 Years
• Weight：60kg
• Laser Source：USA Ipg
• Consumable：Without Consumable, So Free of Maintenance
• Technical Support：Lifelong Support Free of Charge and 24-Hour Online
• Marking Speed：0-7000mm,S
• Marking Size：110*110mm
• Gurantee：1 Year
• Galvo Head：China Top Quality
• Transport Package：Compound Wooden Cases With Exporting Standard
• Specification：ISO9001 & CE
• Trademark：Perfect Laser
• Origin：China
• HS Code：8456100090
• Production Capacity：500 Units, Month

Laser SourseIPG SeriesPulsed, High Energy Ytterbium Fiber LasersMode of operation                                           PulsedPolarization                             randomQ-switched operationOutput power adjustment range10%-100%Nominal average output power W20WCentral emission wavelength         1060-1070 nmEmission Bandwidth (FWHM)       < 10 nmLong-term average power instability< 5%Pulse width, (FWHM)                               100 nsLaser switching ON time                         180 μ secLaser switching OFF time                 180 μ secPulse Repetition Rate* kHz                     20-80 kHzEnergy per pulse (PRR = 20 kHz)     0.95 mJTypical beam quality, M2                             < 1.8Output fiber delivery length                   3mOperating voltage                                         220VMax. Power consumption         600W


Training
1) Free Training by VCD: We will supply the machine with <Training VCD> , <User's Manual> and <Instruction Book> in English for installing, operation, maintenance and trouble-shooting, and shall give technical guide by E-mail, fax, telephone, MSN, ICQ and so on, when you meet some problems of installation, using or adjusting. (Recommend)
2) Free Training in Perfect Laser's Factory: You can send operator to Perfect Laser factory for free training. Perfect Laser will offer professional guide for free. It is direct and effective face-to-face training. Here we have well-assembled equipments, all sorts of tools and testing facility.
Training Time: 2-3 days (Recommend)
3) Our engineer can do a door-to-door instruction training service at your local site. We need your help to deal with the visa formality, prepaid traveling expenses and accommodation to us during the business trip and service period before their dispatch. It's better to arrange a translator for both of our engineers during the training period.



Quality Guarantee and After-sales Services
1) The guarantee period of quality shall be 12 months counting from the date on which the commodity arrives at the port of destination. Except the damage artificially and laser krypton lamp, we are responsible for offering the fittings free of charge during the guarantee period. While user is kindly requested to send the damaged fittings to us by courier with your charge before we send back the alternative fitting parts. After the guarantee of quality period, the parts required repairing or change, if any, shall be reasonable charged.
2) We will give technical guide by email, fax and telephone when user meets some problems on installation, operation, adjusting, maintaining.
3) We offer technical supporting to ensure safety using & maintenance for user:
Ø Operation manual for installation, adjusting, operation, maintaining;
Ø Professional marking software;
Ø Operational marking software backup;
Ø UUUUQuick supplement of key componentsUU with reasonable price.
Ø Life-long after-sales service & consulting service to user.
