Advanced Air Cooling Large Area Plastic Keyboard Fiber Laser Marking Machine

Perfect Laser (Wuhan) Co., Ltd.
  • After-sales Service：Online Support
  • Warranty：3 Years
  • Laser Visibility：Visible
  • Applicable Material：Metal and Non-Metal Material
  • Cooling System：Air Cooling
  • Technical Class：Continuous Wave Laser

Base Info

  • Model NO.：PEDB-400E
  • Laser Wavelength：Fiber Laser
  • Laser Classification：Solid Laser
  • Type：Optical Fiber Laser Marking Machine
  • Marking Method：Scanning Marking
  • Power：20W. 30W and 50W
  • Marking Area：110*110mm
  • Certification：ISO 9001, Ce, FDA
  • Key Words：Laser Marking Machine
  • Usage：Metal, Plastic, Ceramic, Ring, Ear Tag
  • Transport Package：Wooden Cases with Exporting Standard
  • Specification：ISO 9001, CE, FDA
  • Trademark：Perfect Laser
  • Origin：China
  • HS Code：8456100090
  • Production Capacity：300 Units, Month

Description

Machine TypeFiber Laser Marking MachineLaser SoursePEDB-400E  10W  PEDB-400E  20WIPG SeriesPulsed, High Energy Ytterbium Fiber LasersMode of operation                                        PulsedPolarization                          randomQ-switched operationOutput power adjustment range10%-100%Nominal average output power W10W20WCentral emission wavelength      1060-1070 nmEmission Bandwidth (FWHM)    < 10 nmLong-term average power instability< 5%Pulse width, (FWHM)                            100 nsLaser switching ON time                      180 μ secLaser switching OFF time              180 μ secPulse Repetition Rate* kHz                  20-80 kHzEnergy per pulse (PRR = 20 kHz)  0.95 mJTypical beam quality, M2                          < 1.8Output fiber delivery length                3mOperating voltage                                      220VMax. Power consumption      600W
