3D Curved Surface 20W Fiber Laser Marking Machine

Perfect Laser (Wuhan) Co., Ltd.
  • Laser Visibility：Invisible
  • Applicable Material：Metal and Most Non-Metal
  • Cooling System：Air Cooling
  • Technical Class：Pulse Laser
  • Laser Wavelength：Fiber Laser
  • Laser Classification：Solid Laser

Base Info

  • Model NO.：PEDB-500
  • Type：Optical Fiber Laser Marking Machine
  • Marking Method：Scanning Marking
  • Mode of Operation：Pulsed
  • Polarization：Random
  • Output Power Adjustment Range：10%-100%
  • Nominal Average Output Power W：20W
  • Central Emission Wavelength：1060-1070 Nm
  • Emission Bandwidth (Fwhm)：<10 Nm
  • Pulse Width, (Fwhm)：100 Ns
  • Laser Switching on Time：180 μsec
  • Laser Switching off Time：180 μsec
  • Pulse Repetition Rate* kHz：20-80 kHz
  • Transport Package：Wood Crafcase
  • Specification：75kg
  • Trademark：Perfect Laser
  • Origin：Hubei
  • HS Code：8456110090
  • Production Capacity：1000 Units Per Month

Description

Q-switched operationOutput power adjustment range10%-100%Nominal average output power W20WCentral emission wavelength     1060-1070 nmEmission Bandwidth (FWHM)    <10 nmLong-term average power instability<5%Pulse width, (FWHM)                100 nsLaser switching ON time             180 /secLaser switching OFF time         180 /secPulse Repetition Rate* kHz           20-80 kHzEnergy per pulse (PRR = 20 kHz)   0.95 mJTypical beam quality, M2               <1.8Output fiber delivery length          3mOperating voltage                     220VMax. Power consumption     600W

3D Curved Surface 20W Fiber Laser Marking Machine
3D Curved Surface 20W Fiber Laser Marking Machine
3D Curved Surface 20W Fiber Laser Marking Machine
3D Curved Surface 20W Fiber Laser Marking Machine
3D Curved Surface 20W Fiber Laser Marking Machine



Before making a quotation, could you provide us more information:
1. What's your marking material? (stainless steel, aluminum, plastic, mechanical tool, ring...)
2. What's your marking area? (110*110mm, 175*175mm, 200*200mm, 220*220mm, 300*300mm)
3. What kind of marking effect do you want?
4. Are you reseller or end-user?
5. Do you use it on the production line?
6. Do you have any idea about other aspects? Such as shipment, payment, warranty, training, etc.
Detailed information will be sent to you asap upon receipt of your inquiry!
3D Curved Surface 20W Fiber Laser Marking Machine
Company Information:
Perfect laser Co. Ltd. (China) was founded in 1995, located in the core area of "China Optic Valley" - Wuhan city. Occupied with 3000 m2 ground, including R&D building and production area. It has more than 180 employees, most of them are with bachelor degree or even doctorate degree. Executed by reliable quality and reasonable price, our products get favorable sales success and outstanding reputation not domestically in China but also popular in more than 180 countries such as the USA, Italy, Korea, Singapore, Poland, Turkey, Sweden, Saudi Arabia to worldwide.
3D Curved Surface 20W Fiber Laser Marking Machine


Our products:
We produce 12 series product range and 200 different models, attached please kindly find the machine styles and the related price. Also, welcome to visit our website perfectlaserco.en.made-in-china.com to get an overall idea about our products and quality.

Our Certificates:
All the products are approved by CE and ISO 9001:2000 certificate, so every aspect of our machine is perfect and qualified to export to European countries.

Our Advantage:
Perfect Laser is a professional manufacturer for industrial laser machinery, we have a full range of industrial laser machinery, so our agent can just cooperate with us only.
Perfect Laser offer 12 hours quick response.
Perfect Laser machine's key component is all supplied by the global well-known brand, such as institute.
Perfect Laser has mass production, stock keeping immediate delivery.

Contact Information:Perfect Laser Co., Ltd. (China)
Contact: Emily / Sales Department
Add: HengRuichuangzhi Technology Park, No.13 YangQiaohu Road, Jiangxia District, Optical Village, Wuhan, Hubei, China(430200).
