Factory Price 1000W 15000W 2000W CO2 Plywood Die Board Laser Cutting Machine Laser Machinery
WORTHY TALL INDUSTRY CO., LIMITED- Cooling System：Water Cooling
- Technical Class：Continuous Wave Laser
- Applicable Material：Nonmetal
- Structure Type：Gantry Type
- Laser Classification：Fluid Laser
- Laser Technology：Laser Control Fault Cutting
Base Info
- Model NO.：WT-LC2000
- Packing Size：15 Cube
- Effective Cutting Size：1250*2500mm( Other Size Can Be Optional)
- Laser Power：1000W to 3000W
- Cutting Thickness：18-30mm Die Board Wood
- Main Application：Die Board Cutting for Wood Industry
- Laser Type：High Power CO2 Laser
- CO2 Laser Brand：Wt Own Brand and Technology
- Lubrication System：Auto Lubrication
- Max Positioning Speed：30m,Min
- Die Board Pointing Accuracy：0.01mm
- Control Sys：Pmac
- Cutting Gap：1.3PT 2PT 3PT 4PT
- Service：English Engineer Averable
- Graphic Format Supported：Ai, Dst, Dwg, Dxf, Dxp, Las, Plt
- Working Gas：N2 He CO2
- Transport Package：Plywood Packing
- Specification：8500x5500x1800mm
- Trademark：WT
- Origin：Dongguan City China Prc
- HS Code：8456110090
- Production Capacity：1000
Description
Standard Configuration of 1500W laser cutting machineNo. Name Model Quantity 1 1000W/1500W axial laser generator NT1500SM 1 2 working table 1300*2500MM 1 3 Laser Cutting software CypCut 1 4 Industrial chiller for laser generator CW-7500 EN 460H 1 5 Industrial chiller for working table CW-5000 AIS 1 6 Exhaust fan 1100w CZR105E-11 1 7 Exhaust fan 750w CZR90-7 1 8 Air dryer 1.5m³/min ND-10AA 1 9 Voltage stabilizer 30KVA PH-330 1 10 Panasonic AC Servo motor 1.5KW MHME152GCGM 1 11 Panasonic AC Servo motor 3KW 1 12 Panasonic AC Servo motor 0.4KW MHMJ042G1U 1 13 HIWIN Screw R32 R32-10T3-FSI-2025-2186-0.05 2 14 HIWIN Screw R25 R25-10T3-FSI-1411-1539-0.05 2 15 HIWIN Linear Guide Rail 40 HCH40CA2R1610Z0C 1 16 HIWIN Linear Guide Rail 30 HCH30CA2R2960Z0C 1 17 II-VI Lens 38.1mm DIA 190.5mm FL 1 18 II-VI Reflector 50mm DIA 10mm THK 1 19 II-VI CPL Filter 50.0mm DIA 10.0mm THK 1 20 Computer & Monitor Windows 7 1
1000W Laser Generator Key ComponentsNo. Name Manufacturer Country 1 ROOT`S PUMP 1000W NB600AL JAPAN
2
LOW VOLTAGE CONTROL CIRCUIT APPARATUSSIEMENS GERMANY IDEC JAPAN SCHNEIDER GERMANY PHOENIX CONTACT GERMANY 3 RESONANT CAVITY OPTICS SYSTEM II-VI USA 4 COMPUTER OPERATING SYSTEM DELTA TAIWAN
5
PNEUMATIC COMPONENTFESTO GERMANY SMC JAPAN CAMOZZI ITALY
6SWITCH POWER SUPPLY
SEMIKRON
JAPANCONTROL MODULE
7
WATER PATH COMPONENTSMC JAPAN CAMOZZI ITALY 8 LASER POWER SENSOR GENTEC-E CANADA
Machine Features:
Laser Cutting Machine Operating Environment Request:
Assistant Equipment Request to run the Laser Cutting Machine:
Assistant using Gas and Liquid
Applications:
It's widely used in printing, package, die making, advertising signs, metal plates…etc. industries.
Applicable materials:
Plywood, MDF board, acrylic, iron board, steel board, stainless steel board…etc. metal and non-metal materials.
After-sales service:
WT-LC1500-1325 1500W Die Board Laser Cutting Machine Picture:
1000W Laser Generator Key Components
2
LOW VOLTAGE CONTROL CIRCUIT APPARATUS
5
PNEUMATIC COMPONENT
6
SEMIKRON
JAPAN
7
WATER PATH COMPONENT
Machine Features:
- Adopt Gantry style and mixed laser path structure, machine table bed hard and stable in working, small floor space required for machine, laser optical path short, adopt imported reflect mirror and lens from America to make laser path thinner and the cut stronger.
- Intelligent Electronic Laser cutting head coming with automatic touching system, automatically adjustment to adapt the jagged materials and keep cutting precision.
- Adopt Panasonic Servo Drive and Motor system, Taiwan HIWIN precision linear guide rail to keep high precision cutting.
- Highly effective smoke-exhausting system coming with optimized dust collector device to create healthy environment for operator.
- Automatic gas control system to ensure low energy consumption operation power consumption and gas consumption.
- Software is easy to operate, simple and easy to understand
- Be equipped with the optical path gas compensation function that can avoid difference and divergence of the beam and during the conduction process by gas disturbance, and can always maintain the positive pressure of clean gas in the optical cavity to prevent external smoke and enter in.
- Be equipped with the full compensation device in optical path of autonomous developed, to ensure the consistency of the beam diameter and the constancy of the focus in the entire range of processing.
Laser Cutting Machine Operating Environment Request:
- Floor Space/Occupied Area: Length 8Meters Width 5Meters around 40 square meters
- Air-Condition One Set for Laser Generator
- High Requirement Of Foundation: Concrete Foundation, Flat, strong and stable.
Assistant Equipment Request to run the Laser Cutting Machine:
- Air Compressor One Set (Power 5KW or 7.5KW 10HP, match with 0.6MPA gasholder )
- Freezer Dryer One Set (Assistant to be used with Air Compressor)
- 30KW Voltage Stabilizer One Set ( Can be used for both laser and bender machine together)
Assistant using Gas and Liquid
- Assistant using Gas: CO2, He, N2 and O2 (for cutting iron board sheet)
- Liquid: Purified Water
Applications:
It's widely used in printing, package, die making, advertising signs, metal plates…etc. industries.
Applicable materials:
Plywood, MDF board, acrylic, iron board, steel board, stainless steel board…etc. metal and non-metal materials.
After-sales service:
- English-speaking engineer is available for installation and training under buy's cost around 5days.
- English software, installation and related training instructions and videos are available for end-users.
- In case of any problems or questions about laser technology you can always refer to WT Laser.
- With our customer-orientated service support, maintenance and repair costs will be kept low.
- One year guarantee for machine is promised.
WT-LC1500-1325 1500W Die Board Laser Cutting Machine Picture:
