Metal Fiber Laser Cutter Industry Laser Machine Laser Equipment
Jinan Laser Max Machinery Tech Co., Ltd.- After-sales Service：on Line Tech Support
- Warranty：3 Year
- Application：Petroleum Machinery Manufacturing, Agriculture Machinery, Automotive Industry, Advertising Industry, Metalwork Industry
- Cooling System：Water Cooling
- Technical Class：Continuous Wave Laser
- Applicable Material：Metal
Base Info
- Model NO.：LM1530
- Structure Type：Gantry Type
- Laser Classification：Semiconductor Laser
- Laser Technology：Laser Control Fault Cutting
- Working Area for Metal Sheet：3000mm*1500mm
- Y-Axis Stroke：3000mm
- X-Axis Stroke：1500mm
- Z-Axis Stroke：120mm
- X/Y Axis Position Accuracy：0.03mm
- X/Y Axis Reposition Accuracy：0.02mm
- Max. Moving Speed：100m,Min
- Maximum Acceleration：1.0g
- Transport Package：4600mm*2450mm*1700m
- Specification：3000kg
- Trademark：LaserMax
- Origin：China
- HS Code：845611
- Production Capacity：1000 Sets,Year
Description
Basic Info.
Model NO. LM1530 Structure Type Gantry Type Laser Classification Semiconductor Laser Laser Technology Laser Control Fault Cutting Working Area for Metal Sheet 3000mm*1500mm Y-Axis Stroke 3000mm X-Axis Stroke 1500mm Z-Axis Stroke 120mm X/Y Axis Position Accuracy 0.03mm X/Y Axis Reposition Accuracy 0.02mm Max. Moving Speed 100m/Min Maximum Acceleration 1.0g Transport Package 4600mm*2450mm*1700m Specification 3000kg Trademark LaserMax Origin China HS Code 845611 Production Capacity 1000 Sets/YearProduct Description
Technical Parameters| Model | LM3015 |
| Dimension | 4600*2450*1700mm |
| Laser power | 1KW |
| Working area for metal sheet | 3000*1500mm |
| Y-axis stroke | 3000mm |
| X-axis stroke | 1500mm |
| Z-axis stroke | 120mm |
| X/Y axis position accuracy | ±0.03mm |
| X/Y axis reposition accuracy | ±0.02mm |
| Max. Moving speed | 100m/min |
| Maximum acceleration | 1.0G |
| Max. Working capacity of sheet table | 900kg |
| Specified voltage and frequency | 380V/50Hz/60Hz/60A |
| Continuous working time | 24h |
