High Speed CO2 Laser Marking Machine Hsco2-30W

Zhejiang Holy Laser Technology Co., Ltd.
  • Laser Visibility：Visible
  • Applicable Material：Nonmetal
  • Cooling System：Air Cooling and Water Cooling
  • Technical Class：Pulse Laser
  • Laser Wavelength：CO2 Laser
  • Laser Classification：Semiconductor Laser

Base Info

  • Model NO.：HSCO2-30W
  • Type：CO2 Laser Marking Machine
  • Marking Method：Scanning Marking
  • Current：AC
  • Laser Type：CO2
  • Usage：Advertising
  • Apply Area：Wood, Plastic, All Nonmetal Materials
  • Transport Package：Wooden Packing
  • Specification：CE FCC FDA
  • Trademark：holylaser
  • Origin：Yiwu
  • HS Code：8456100090
  • Production Capacity：1000sets,Month

Description

Model NO.

HSCO2-30W/60W

Marking scope

70*70,110*110,140*140,175*175,300*300(optional)

Response time

0.8ms

Laser wavelength

10.64±10nm

Output power

<30W/60W/100W/150W

Min.line width

0.1mm

Marking speed

≤7000mm/s

Repeat ability precision

±0.01mm

Marking depth

≤2mm/6mm

Pluse frequency

800W/1.5W

Cooling

Air cooling&water cooling

Marking sryle

plane/3D rotary


Samples showing:
High Speed CO2 Laser Marking Machine Hsco2-30W

Applicable Industry:
High speed CO2 laser marking machine HSCO2-30W can mark a variety of non-metal materials. Widely Used in clothing accessories, medicine packaging, building ceramics, beverage packaging, rubber products, shell nameplates, craft gifts, electronic components, leather and other industries.

Available material:
High speed CO2 laser marking machine HSCO2-30W can marking logo, brand, name, letter, picture, design on the surface of all nonmetal materials, like plastic, acrylic, wood, bamboo, paper, leather, glass, cloth, epoxy, etc. It can also cut nonmetal materials, cutting depth no more than 5mm.
Our high speed CO2 laser marking machine HSCO2-30W not only can mark on the surface of plane object also can mark on the round object with our rotary.

Machine Advantages:
1. All laser source coherent is imported from USA. Low power consumption, cost effective and long lifespan, maintenance-free. Can continue work more than 20000, the machine can be used 5-10 years if keep the environment cool and clean.
2. Stable laser output and good laser beam quality
3. Be compatible with AUTOCAD, CORELDRAW, PHOTOSHOP, Support PLT, PCW, DXF, BMP, PCX, JPG.
4. The machine can be used to mark common picture, bitmap graphics, date, serial number, bar code, letter, 2D code, automatic jump codes, etc.
5. Cooling way: Water cooling.
6. Can not only mark plane surface, but also roll materials and such as cylinders, pencil, vase, flute, bottle and so on.

Factory Profile:
1. Supported by the Yiwu City government
2. Cooperate with the Zhejiang University, update for technology
3. We are the manufacturer, our price are more competitive.
4. With 15 years history on researching and producing all kind of laser machine
5. Our company welcomes AGENTS all over the world.
High Speed CO2 Laser Marking Machine Hsco2-30W

After-sale service:
1. One year guarantee period for product quality.
2. Lifelong maintenance and spare parts supply.
3. Free design of fixtures as customers required.
4. Free training for machines installation and operation of the staffs.

Customer visit:
High Speed CO2 Laser Marking Machine Hsco2-30W

Certification:
High Speed CO2 Laser Marking Machine Hsco2-30W


Contact us:

Warmly welcome you contact us directly for more information! ! !
Warmly welcome you to visit our factory! ! !
