Crystal Glass 3D Laser Subsurface Engraving Machine (HSGP-3KC)
Zhejiang Holy Laser Technology Co., Ltd.- Application：Crafts Industr, Advertising Industry
- Cooling System：Air Cooling
- Technical Class：Continuous Wave Laser
- Automatic Grade：Automatic
- Applicable Material：Nonmetal
- Type：Flat-Plate
Base Info
- Model NO.：HSGP-3KC
- Laser Classification：Semiconductor Laser
- Engraving Method：Lattice Engraving
- Power：Small Power
- Drive Type：Stepper Drive
- Engraving Machine Type：Laser Engraving Machine
- Current：AC
- Laser Type：Semiconductor
- Usage：Glass
- Certification：SGS, Ce, FDA, TUV
- Transport Package：Alunimium Material Box
- Specification：CE FCC FDA SGS
- Trademark：holylaser
- Origin：Yiwu, Zhejiang
- HS Code：8456110090
- Production Capacity：50 Sets Per Month
Description
Type
HSGP-5KB
HSGP-4KB
HSGP-3KC
HSGP-3KD
Laser wavelength
532nm
Laser frequency
5KHZ(5000HZ)
4KHZ(4000HZ)
3KHZ(3000HZ)
3KHZ(3000HZ)
Max.pulse energy
1.2mj
Laser power
3w
Pulse width
7ns
Beam quality
M2<1.5
Max.engraving speed point
≤300000dots/min
≤240000dots/min
≤180000dots/min
≤180000dots/min
Max.marking scope
300*400*130mm
300*400*130mm
300*400*130mm
150*200*80mm
Laser head
one
Resolution
800DPI-1200DPI
Focal length
≥100mm
Focus diameter
0.02mm
Cooling
Air cooling
Application materials
Crystal Glass Etc
Device input power
AC220V±10%50-60HZ
Packaging and shipping:
Factory Profile:
Zhejiang holy laser technology Co.LTD has worked hard to become the global leader in manufacturing of laser equipment.All our products has passed the CE,FCC,SGS,TUV and FDA special for American market.2012,company has obtained 6 patents certificate for computer software technology.Holy laser has been in the laser business since established. we strive to update our technology in the direction of green ,environment-friendly and energy saving .
After-sale service:
1.We will train you the technology at our factory for free.
2.Our engineers could serve you 24 hours online.
3.We will send you the video show you how to use the machine step by step.
4.24 months guarantee for whole machine.
5.Machine has been adjusted before delivery.
Contact us:
Warmly welcome you visit our factory! ! !
Warmly welcome you contact us directly for more information! ! !
