Laser Equipment

Compact 5030 7045 9060 Semi-Automatic CO2 Desktop Laser Cutting Machine for Home Use Hobby Fabric/Textile/Woven Labels/Paper/Wood/Stone/Acrylic/Leather/Glass

Suzhou Aeon Laser Technology Co., Ltd.
  • After-sales Service:Free Online Support
  • Warranty:1 Year
  • Application:Leather Industry, Crafts Industr, Advertising Industry, Education
  • Cooling System:Water Cooling
  • Technical Class:Continuous Wave Laser
  • Automatic Grade:Semi-Automatic

Base Info

  • Model NO.:MIRA7
  • Applicable Material:Nonmetal
  • Type:Flat-Plate
  • Laser Classification:Gaseous Laser
  • Engraving Method:Vector Engraving
  • Power:60W 80W RF30
  • Working Area:700mm*450mm
  • Drive:Stepper Motor Drive
  • Software:Lightburn,Rdworks
  • Table Type:Blade + Honeycomb
  • Focus Lens:φ18mm 2inch,50.8mm
  • Transport Package:Woodenbox
  • Trademark:Aeon Laser
  • Origin:Suzhou China
  • HS Code:8456110090
  • Production Capacity:3000,Year

Description

Working Area700*450mm (17 3/4″ x 27 1/2″)Machine Size1106mm*883mm*543mm (43 1/2″ x 34 3/4″ x 20 5/8″)Machine Weight392 lbs. (178kg)Work TableHoneycomb + BladeCooling typeFan Cooled (3000) Water ChillerLaser tube typeC02 glass tubeLaser power60W/80W/RF30WZ-Axis Travel150mm(5-⅞")Air Assist105W Built-In Air PumpBlower330W Built-In Exhaust FanInput Voltage120V AC Single PhaseRated Power1200WEngraving Speed0-1200mm/second (0 - 47 1/4" /second)Cutting Speed0-680mm/second (0 - 26 49/64"/second)Cutting Thickness0-20mm (depends on different materials)Max Acceleration Speed5GLaser Optical Control0-100% Set by softwareMinimum Engraving SizeMinimum Font Size 1.0mm x 1.0mm(English Letter) 2.0mm*2.0mm(Chinese Charactor)Max Scanning Precision1000DPILocating Precision<=0.01mmRed Dot PositioningCombiner TypeBuilt-in WIFIIncludedAuto FocusIncludedEngraving SoftwareRD works/LightBurnGraphic Format SupportedAI/PDF/SC/DXF/HPGL/PLT/RD/SCPRO2/SVG/LBRN/BMP/JPG/JPEG/PNG/GIF/TIF/TIFF/TGACompatible SoftwareCorelDraw/Photoshop/AutoCAD/All kinds of Embroidery SoftwareAdd-OnsRoller Rotary, Rotary Chuck, Stand, Fume Extractor, Remote Control, CameraCompact 5030 7045 9060 Semi-Automatic CO2 Desktop Laser Cutting Machine for Home Use Hobby Fabric/Textile/Woven Labels/Paper/Wood/Stone/Acrylic/Leather/GlassCompact 5030 7045 9060 Semi-Automatic CO2 Desktop Laser Cutting Machine for Home Use Hobby Fabric/Textile/Woven Labels/Paper/Wood/Stone/Acrylic/Leather/GlassCompact 5030 7045 9060 Semi-Automatic CO2 Desktop Laser Cutting Machine for Home Use Hobby Fabric/Textile/Woven Labels/Paper/Wood/Stone/Acrylic/Leather/GlassCompact 5030 7045 9060 Semi-Automatic CO2 Desktop Laser Cutting Machine for Home Use Hobby Fabric/Textile/Woven Labels/Paper/Wood/Stone/Acrylic/Leather/Glass
Application Materials of Compact 5030 7045 9060 Semi-automatic CO2 Desktop Laser Cutting Machine for Home Use Hobby Fabric/Textile/Woven Labels/paper/Wood/Stone/Acrylic/Leather/GlassLaser CuttingLaser EngravingAcrylicAcrylic*WoodWoodLeatherLeatherPlasticsPlasticsFabricsFabricsMDFGlassCardboardRubberPaperCorkCorianBrickFoamGraniteFiberglassMarbleRubberTile River Rock Bone Melamine Phenolic *Aluminum *Stainless Steel

*Cannot cut hardwoods like mahogany

*CO2 lasers only mark bare metals when anodized or treated.
Compact 5030 7045 9060 Semi-Automatic CO2 Desktop Laser Cutting Machine for Home Use Hobby Fabric/Textile/Woven Labels/Paper/Wood/Stone/Acrylic/Leather/Glass

Compact 5030 7045 9060 Semi-Automatic CO2 Desktop Laser Cutting Machine for Home Use Hobby Fabric/Textile/Woven Labels/Paper/Wood/Stone/Acrylic/Leather/Glass

FAQ
1 Q: Can the machine engrave and cut?
A. Yes, even on the same Job, you can do settings with different colors in the software and also can make holes.
2. Q. Is the machine must work with computers?
A. Must connect with computer with USB cable when you change the settings of the machine. for the design files, you can transfer the file with a USB memory stick to the machine, Or can download it to the machine directly with a USB cable from the computer.
3. Q. Can the machine be split so it can fit into my doors?
A. Such as laser engraving cutting machine model of WHL3050, WHL4060, which can the legs separate from the main body of the machine.
4. Q. How long has the laser tube been working well?
A. Unfortunately we cannot confirm this.
it is about 4000+ hours for ordinary co2 laser tube 10,000+ hours for Reci brand co2 laser tube 6000+ hours for Pomelo Laser co2 laser tube
5. Q. Can you explain what the differences are between the different watt laser tubes?
A: Usually, the power of the laser tube is decided by two parameters:
1. The length of the laser tube( The longer the laser tube, is the more powerful).
2. The Diameter of the Laser tube (The bigger the laser tube, the more powerful).
AND bigger watt laser tube can cut thicker materials, however, a bigger watt has a big laser beam, therefore, For engraving, It's. better to use small watt laser tube-like 60watt or 80watt.)
6. Q.How do I know the laser tube is nearly used up?
A: The normal color of the laser beam is purple while working. When a laser tube is dying the color will become white
