• Model NO.：PEDB-400H
• Laser Wavelength：Fiber Laser
• Laser Classification：Solid Laser
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Product Name：Laser Marking Machine
• Certification：CE, FDA, ISO
• After Sales Service Scope：Overseas
• Application：Marking on Metal and Some Hard-Non Metal
• Material：Stainless Steel, Aluminum, Cooper, Ect.
• Diode Lsaer Module：USA Imported Name Brand
• Q Switch：Famous British Brand
• Transport Package：Wooden Case
• Specification：ISO 9001 & CE&FDA
• Trademark：Perfect Laser
• Origin：China
• HS Code：8456100090
• Production Capacity：500 Sets, Month

Laser Source
 IPG Series
 Pulse, high energy ytterbium doped fiber laser
 Operating Mode
 Pulse
 Polarization
 Random
 Average output power
 10W - 50W
 Central emission wavelength
 1060-1070 nm, Q switch operation Output power adjustment range is 10% -100%
 Transmit bandwidth(FWHM)
 <10nm
 Long-term average power instability
 <5%
 Pulse width (FWHM)
 100ns
 Laser connection time
 180 microseconds
 Laser disconnect time
 180 microseconds
 Pulse repetition rate (kHz)
 20-80kHz
 Per pulse energy (PRR = 20 kHz)
 0.95 MJ
 Beam quality
 <1.8
 Output fiber transmission length
 3m
 working voltage
 220V
 Maximum power consumption
 600W
 Net size
 70*20*50cm
 Laser System
 Scanning speed
 0-7000mm/s
 Marking speed
 0-8000mm/s
 Marking size
 110mm×110mm (F-theta 160)
 Spot size
 ≤ 40 micron (F-theta 160)
 Cooling system
 Air cooling
 Pilot laser
 650 nm laser diode, red light marking guide
 Continuous working time
 ≥16h
 Humidity
 45 to 85% (without condensation)
 Working temperature
 0~40ºC
 Control system
 Laser marking (Chinese version)
