• Model NO.：PEDB-400D
• Laser Wavelength：Fiber Laser
• Laser Classification：Solid Laser
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Product Name：Fiber Laser Marking Machine
• Power：10W 20W 30W 50W
• Speed：1-7000mm,S
• Marking Content：Logo, Sign, Letter, Character, Word, Numbers etc
• Control Type：Computer with Professional Software
• Software Type：Ezcad Original
• Rotary Device：Yes, It Is Available for Rotary Marking
• Marking Depth：0.01 ~0.3mm
• Certification：CE, FDA
• Pulse Width, (Fwhm)：100 Ns
• Transport Package：Wood Crafcase
• Specification：75kg
• Trademark：Perfect Laser
• Origin：Hubei
• HS Code：8456110090
• Production Capacity：1000 Units Per Month

Q-switched operation

Output power adjustment range

10%-100%

Nominal average output power W

20W

Central emission wavelength

1060-1070 nm

Emission Bandwidth (FWHM)

<10 nm

Long-term average power instability

<5%

Pulse width, (FWHM)

100 ns

Laser switching ON time

180 μsec

Laser switching OFF time

180 μsec

Pulse Repetition Rate* kHz

20-80 kHz

Energy per pulse (PRR = 20 kHz)

0.95 mJ

Typical beam quality, M2

<1.8

Output fiber delivery length

3m

Operating voltage

220V

Max. Power consumption

600W

Before making a quotation, could you provide us more information:
1. What's your marking material? (stainless steel, aluminum, plastic, mechanical tool, ring...)
2. What's your marking area? (110*110mm, 175*175mm, 200*200mm, 220*220mm, 300*300mm)
3. What kind of marking effect do you want?
4. Are you a reseller or end-user?
5. Do you use it on the production line?
6. Do you have any idea about other aspects? Such as shipment, payment, warranty, training, etc.

Detailed information will be sent to you asap upon receipt of your inquiry!


Company Information:
Perfect laser Co. Ltd. (China) was founded in 1995, located in the core area of "China Optic Valley" - Wuhan city. Occupied with 3000 m2 ground, including R&D building and production area. It has more than 180 employees, most of them are with a bachelor degree or even a doctorate degree. Executed by reliable quality and reasonable price, our products get favorable sales success and outstanding reputation not domestically in China but also popular in more than 180 countries such as the USA, Italy, Korea, Singapore, Poland, Turkey, Sweden, Saudi Arabia to worldwide.





Welcome to contact us for perfect laser engraving cutting solution
Contact me:
Perfect Laser Co., Ltd. (China)
Contact: Susie / Sales Department
Add: HengRuichuangzhi Technology Park, No.13 YangQiaohu Road, Jiangxia District, Optical Village, Hubei, China(430200).
