• Model NO.：PEDB-400B
• Laser Wavelength：Fiber Laser
• Laser Classification：Fiber Laser
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Production Time：3~5 Working Days
• Payment Method：,T in Advance
• Gurantee：1 Year
• Transport Package：Sea-Worthy Packing or Air-Worthy Packing
• Specification：ISO 9001 & CE
• Trademark：Perfect Laser
• Origin：Hubei, China
• HS Code：8456100090
• Production Capacity：100 set,month

PEDB-400CPEDB-400DTypePortableDesktopColorfulFloor StandPC includes or notNot includes PCincludes PCLaser SourceIPG Series:Pulsed, High Energy Ytterbium Fiber LasersMode of operationPulsedPolarization:  randomNominal average output power10W - 20WCentral emission wavelength:  1060-1070 nm ,Q-switched operation Output power adjustment range 10%-100%Emission Bandwidth (FWHM)  <10 nmLong-term average power instability<5%Pulse width, (FWHM)100 nsLaser switching ON time180 μsecLaser switching OFF time180 μsecPulse Repetition Rate* kHz20-80kHzEnergy per pulse (PRR = 20 kHz)0.95 mJTypical beam quality, M2<1.8Output fiber delivery length3mOperating voltage:220VMax. Power consumption:600WNet Dimensions: 70*20*50cm58*22*50cm                                            80*38*72cm  70*20*50cm143*62*101cmNet Weight:                 44 kgs53 kgs44 kgs130 kgsGross Weight:60 kgs70 kgs60 kgs150 kgsLaser systemScanning Speed:0-7000mm/sMarking Speed:   0-5000mm/sMarking size:110mm×110mm (F-theta 160)Spot size:      ≤ 40 micron (F-theta 160)Cooling unit:Air cooledPilot laser:                  650nm diode laser, visible red light for marking guideContinuous working time:≥16hHumidity:45~85% (no condensation)Operating temperature:0~40 degreesControl unitsCT-MARK (English Version)Remark:
1> PEDB-400A / B / C type, it is very compact type, industry PC, Mouse and Monitor are not included in the quotation. Customer can use your own computer or laptop to control it.
2> PEDB-400D Floor type's quotation includes industrial PC / Mouse / Monitor.
Contact us :
Perfect Laser Co., Ltd. (China)
Contact: Lisa/sales department
Warmly welcome to send us inquiry below for more details ~
