• Model NO.：625
• Type：YAG Laser Marking Machine
• Marking Method：Mask Pattern Marking
• Electrical Requirements：AC220V±10%.50Hz.10AMP
• Scan Head：High Precision Digital Scan Head
• Unit Power：0.5kw
• Beam Quality：M2:1.2~1.8
• Operational Temp Range：10-40c
• Cooling Mode：Air Cooled
• Warranty：2 Years on Laser Source
• Operational Humidity Range：5%-75%, Non-Condensing
• Net Weight：180kg
• Dimensions：820*690*1550mm
• Transport Package：Plywood Case or as Your Request
• Specification：SGS,CE
• Trademark：Dapeng
• Origin：China Shenzhen
• HS Code：8456100090
• Production Capacity：100set,Month

Model   DML-F10/20/30/50Laser Power:10W,20W,30W,50WWavelenth:1064nmStandard Marking Area:100mm*100mmOptional Marking Area:150mm*150mm,200mm*200mm,300mm*300mmMarking Speed:≤7000mm/sMinimum Line Width0.02mmMinimum letterEnglish: 0.2 x 0.2mmMarking Depth0 ~0.5mmLocation precision≤0.01mmResetting positioning accuracy0.002Beam QualityM2:1.2~1.8Electrical Requirements:Ac220V±10%.50HZ.10AmpCooling modeAir cooledScan HeadHigh Precision Digital Scan HeadUnit Power<0.5kwOperational Temp Range10-40COperational Humidity Range5%-75%, Non-condensingWarranty:2 years on laser sourceDimensions:820*690*1550MMNet Weight180KG

Software:True Type FontsSingle Stroke FontsElliptical TextSequential Serial NumbersCustomizable Auto DatingBarcodesQR Codes and Data MatrixUID WizardLogosPhoto Quality Images - JPG, TIF, GIFCorel Draw, Adobe IllustratorRaster GraphicsVector GraphicsCAD Files
Applications:

We offer Fiber Laser Marking Machine with following applications:
Laser marking of metal & non-metal material and products: Stainless steel, gold, silver, copper, aluminium alloy, hardware, tools, acrylic, ceramics, plastics, organics, thermo-elastomer rubbers, paper and others
Hall marking on Gold
Automotive & Engineering Industries
Electronic industry: Capacitor, inductor, PCB, IC, connector, control panel and other  instruments
Others: Cosmetics, food package, bottle, gift, advertisement & sign crafts, craft & gift making

We also provides laser sources and spare parts to the laser machine manufacturers in China and surrounding countries.

MATERIALS:Stainless SteelSteelAluminum, CarbideNickelTitaniumCast IronChromePainted Metal AlloysMulti-Coated MetalsPlastics/RubberBacklit ButtonsPolycarbonatePVCCompositesMany more materials



Company
 Founded in 2005, Shenzhen Dapeng Laser Technology Limited is the market leader in developing, manufacturing and

servicing products and systems for laser marking, laser welding, laser cutting and engraving. The company provides

equipment to a wide range of markets including medical industries, jewelry, automotive, aerospace, military,

semiconductor and solar industries as well as the battery, electric vehicle, electronics and general industrial markets.

With a decade of cumulative laser equipment design and manufacturing expertise, Dapeng Laser is able to offer standard

and custom designs that solve challenging OEM applications. Dapeng Laser is CE and FDA certified. Our laser marker

systems are highly precise, most reliable, and cost-effective. We have sold over thousands of systems worldwide for last

10 years. Our products can be found in Europe, America, Russia, India, Vietnam, Thailand, Indonesia, Egypt, Brazil,

Colombia, and South Africa, among others.

Since our inception, customer support has been a top priority and that standard still remains today. We hope that we will

have a chance to give you a great laser solution with Dapeng Laser products.

Our mission is to be a full service provider of industrial laser equipment that emphasize the quality, reliability, safety, cost

effectiveness, and technical support.

China. Last year 2016 we sold more than 5000sets of laser systems, about 80% are sold in domestic market, and others

we sold to America, Spain, Poland, India, Egypt and many other countries. Post Code- 518105 T.+86 755 3695 8011  F.+86 755 2163 6702  Made-in-china Homepage- http://dplaser.en.made-in-china.com/  FacebookPage- https://dplaser.en.made-in-china.com
