• Model NO.：DW1410
• Laser Technology：Laser Flame Cutting
• Laser Power：60W,80W,100W,130W,150W for Your Reference
• Machine Application：Non Metal, Such as Wood, Acrylic, MDF, Leather etc
• Machine Warranty：24 Months
• Cutting Thickness：0-30mm
• Graphic Format Supported：Ai, BMP, Dst, Dwg, Dxf
• Control Configuration：Redcam
• Motor：Servo or Stepper Motor
• System：Leetrol or Redcam
• Guide Rail：Taiwin Hiwin Square Rail
• Certification：Ce, FDA
• Transport Package：Plywood Box, Free of Fumigation
• Specification：Machine size can be customized
• Trademark：Dwin
• Origin：China
• HS Code：8456100090
• Production Capacity：50sets Per Month

1ModelDW1410 laser engraving machine used2Working area140cm*100cm / 35in*24in (L*W)3Laser power40W/60W/80W/100W/150w4Laser typeCO2 sealed laser tube,water-cooled5Engraving speed0-60000mm/min6Cutting speed0-10000mm/min7Power supply220V±10% /50HZ , 110V±10%//60HZ8Min. shaping characterLetter 1.0 x 1.0mm9Graphic format supportedBMP, PLT, DST, DXF, AI,CDR10Software supportedCorelDraw, PhotoShop, AutoCAD11Laser Output Control1-100% software setting12Highest Scanning Precision2500DPI
Machine Feature
Carbon dioxide laser as an energy source, combined with electronic, mechanical, computer technology
developed. Laser head and the workpiece does not contact, do not scratch the surface, the kerf, high
precision, is the ideal choice for a variety of processing industries.
