• Model NO.：GS-3015
• Laser Technology：Laser Control Fault Cutting
• Type：Fiber Laser Cutter
• Fiber Laser Soruce：Chinese High Quality Laser Generator
• Laser Power：3kw
• Working Area：1300mm*2500mm, 1500mm*3000mm, 2000mm*4000mm
• Warranty：One Year for Whole Machine
• Consumable Parts：Nozzle & Protecting Lens
• Optional Parts：Exchangeable Worktable, Uploading System, Cover
• Transport Package：Packed by Plywood
• Specification：ISO, CE, FDA, SGS
• Trademark：GLORYSTAR
• Origin：Dongguan, China
• HS Code：8456100090
• Production Capacity：800 Sets,Year

Basic Info.

Model NO. GS-3015 Laser Technology Laser Control Fault Cutting Type Fiber Laser Cutter Fiber Laser Soruce Chinese High Quality Laser Generator Laser Power 3kw Working Area 1300mm*2500mm, 1500mm*3000mm, 2000mm*4000mm Warranty One Year for Whole Machine Consumable Parts Nozzle & Protecting Lens Optional Parts Exchangeable Worktable, Uploading System, Cover Transport Package Packed by Plywood Specification ISO, CE, FDA, SGS Trademark GLORYSTAR Origin Dongguan, China HS Code 8456100090 Production Capacity 800 Sets/Year

Product Description

                                                      [Glorystar] 1000W Laser Metal Cutter



Features:
Machine Frame: precisely welded by argon arc, whole structure is gantry type; 600 ºC high temperature annealing treatment and 12 meters large CNC gantry fine milling ensure the frame can regularly run for 20 years without deforming.
Main Parts: IPG/Rofin laser generator, high-strength aluminum alloy cross girder, German cutting head, Japanese servo motor, Taiwan screw ball and guide-rail or imported pinion rack, French precise helical gearbox.
Software: automatic edge finding and two points location; kerf compensation; leapfrog cutting; breakpoint resumption;
Auxiliary Parts: automatic lubrication system; auto-following system; ball bearing and pneumatic auxiliary system for sheet metal loading; foldable cart for leftover collection.
Optional Parts: protection cover; automatic material uploading system; extractor; exchangeable worktable etc.

Application:
metal forming, aviation, aerospace, electronics, appliance, subway spare parts, automobile, grain machinery, textile machinery, engineering machinery, high precision accessories, vessel, metallurgy, elevator, arts and crafts, tool processing, decoration, advertising, metal processing service, parking system etc.

Applicable Materials*:
The laser cutting can replace CNC punching and wire cutting in some way. It's mainly used for laser cutting on metal plate and tube, e.g., stainless steel, carbon steel, alloy steel, silicon steel, spring steel, aluminum, aluminum alloy, galvanized plate, pickle plate, galvalume plate, copper, silver, gold and titanium etc.
*Not every model can cut aluminum, copper etc, for more information, please contact us.

Before buying a metal laser cutting system, what shoud you do?
1. What kind of material do you need to cut? (stainless steel, mild steel...)
2. What working size do you need? (1300mm*2500mm, 1500mm*3000mm...)
3. What is the most common and maximum cutting thickness of the material?
4. What will be the material used for after cutting?

GS is the most popular mode of fiber laser cutting machine. more than 2000sets of GS fiber laser cutting machines are working in the market. GS enjoys high reputation in the market by its high quality and price ration as well as high stability and efficiency. GS enjoy the honour of well-known product in China as well some overseas market. Now we have GS third generation to appreciate the customers.

Technical parameters

Model	GS-3015	GS-4015	GS-4020	GS-6015	GS-6020
Laser Power (W)	1000-6000 (Optional)	1000-6000 (Optional)	1000-6000 (Optional)	1000-6000 (Optional)	1000-6000 (Optional)
Working Area (MM)	3000*1500	4000*1500	4000*2000	6000*1500	6000*2000
Total Power Consumption (KW)	12<30	12<30	12<30	12<30	12<30
Dimensions (MM)	4800*2300*2000	6000*2700*2000	6000*3200*2000	8100*2300*2000	8300*3200*2000
Weight (T)	5	5.5	6	7.2	8

Quality:
First class modern production plant and showroom in China. CE SGS and ISO certified. Machine is inspected by the precision laser collimator to ensure the flatness and verticality. Every machine will be tested strictly before sending out.

Warranty & After-Sales Services:
The whole set of machine warranty is one year, extended warranty to be negotiated.
We offer manual, video, online guidance and remote assistance. Technician is available to serve at your place for installation and training. You can also send operator to our factory for learning.

Want to know more about details? Visit and inquire now!
Website: glorystarlaser.en.made-in-china.com
