• Model NO.：PEDK-9060
• Laser Technology：Laser Control Fault Cutting
• Model：13090
• Working Area：1300*900mm
• Laser Power：60,80,100,120,150W×2
• Engraving Speed：1-60000mm,Min
• Cutting Speed：1-10000mm,Min
• Repeat Location Accuracy：± 0.0125mm
• Voltage：220V(±10%) 50Hz
• Cooling Mode：Water Cooling and Protect System
• Cutting Platform：Professional Thickening Strip or Honeycomb Work Ta
• Controlling Mode：Professional Control System
• Transport Package：Sea-Worthy Packing or Air-Worthy Packing
• Specification：CE & ISO 9001: 2000
• Trademark：Perfect
• Origin：China
• HS Code：84572000
• Production Capacity：5000 Sets,Year

Basic Info.

Model NO. PEDK-9060 Laser Technology Laser Control Fault Cutting Model 13090 Working Area 1300*900mm Laser Power 60/80/100/120/150W×2 Engraving Speed 1-60000mm/Min Cutting Speed 1-10000mm/Min Repeat Location Accuracy ± 0.0125mm Voltage 220V(±10%) 50Hz Cooling Mode Water Cooling and Protect System Cutting Platform Professional Thickening Strip or Honeycomb Work Ta Controlling Mode Professional Control System Transport Package Sea-Worthy Packing or Air-Worthy Packing Specification CE & ISO 9001: 2000 Trademark Perfect Origin China HS Code 84572000 Production Capacity 5000 Sets/Year

Product Description

Hot Sell Manufacturer Laser Engraver Engraving Machine CO2 Laser Cutter Price for Wood/acrylic


Model	13090 (II)
Working Area	1300× 900mm
Laser Power	60/80/100/120/150W× 2
Laser Type	Hermetic and Detached Co2 Laser Tube
Engraving Speed	1-60000mm/min
Cutting Speed	1-10000mm/min
Repeat Location Accuracy	± 0.0125mm
Laser Power Controlling	1-100% Manual Adjustment and Software Controlling
Voltage	220V(± 10%) 50Hz
Cooling Mode	Water Cooling and Protect System
Cutting Platform	Professional Thickening Strip or Honeycomb Work Table
Controlling Mode	CNC Professional Control System
Support Graphics Formats	BMP, HPGL, JPEG, GIF, TIFF, PCX, TAG, CDR, DWG, DXF Compatible HPG Order To Support DXF, WMF, BMP, DXT
Power Controlling Mode	Laser Energy Combining Movement Control System
Control Software	Original  Perfect Laser Engraving & Cutting Software

Do you have online chating tools so that we can chat online.
Description:
Double Heads Laser Engraving Machine is developed by our company to solve the problem of heavy processing volume demanding with tight processing time, which has the advantages of high-efficiency and low-input. Our Double Heads Laser Engraving Machine has obtained national patent protection. Two laser heads of this laser engraving machine can simultaneously carving and cutting, but also can work separately; Besides, the laser power can be controlled separately. Two laser head position can be relative adjusted at will.

Features:
1. The X-axis guide rail applied double ones, installed two sets of laser head, and controlled by two motors. Thus the position of two laser heads can be located at will, and therefore can avoid material waste due to fixed position of the traditional double head laser can not be adjusted or inconvenient adjustments.
2. Large-scope cutting with single laser head
3. High efficient small scope cutting by double laser head.
4. Advanced LCD Touch Screen+ USB port+ DSP Offline Control, which can not only work without computer, but also connect to U disk, USB communication.
5. Imported high precision linear guide rail and professional optical system, dustproof and lubricate, which improve the engraving quality and prolong machine lifetime.
6. Special Front and back running-through design, the unique door for the limitless engraved materials through.
7. Professional Honeycomb or Strip work table, which meet the needs of diversified laser procession;
8. Water Cooling System with Alarm Protection, adopt CW-3000 Water Chiller with temperature display, which can avoid over burning, to protect the water circulation from electricity-off.
9. Equipped with luxury Consumables, Imported Focus Lens and reflect mirror, Chinese Best Quality Laser Tube, Reci Laser Tube and RF metal tube for your choose, makes high efficiency and steady.
10. High speed stepper subdivision driver control, numeral timing, simulation quantum control laser power, little error, repetition high precision, engrave 1× 1mm little English character perfect.
11. Red Light Pointer realizes the exact position without laser.
12. Optional Motorized up-down work table with Auto Focus Function, very good for precise focusing and different cutting depth requirement for lots of material;
13. Optional 3D Rotary System, engrave circumrotately 360 degree, applicable in column or cone work piece surface.


Application Fields:
Available Materials:
1. It's widely used in advertisement material, such as acrylic engraving and cutting, plastic engraving and cutting, PVC board engraving and cutting, rubber plate engraving, seal engraving, organic glass engraving, plexiglass engraving, marble engraving, granite engraving, Gum engraving, EVA materials engraving, paper engraving and cutting.
2. Wood material: Wood engraving and cutting, MDF engraving, plywood cutting, bamboo engraving.
3. Garment material: Leather engraving and cutting, textile engraving, fabric engraving, cloth engraving, shoe engraving, jeans engraving, carpet engraving and cutting, toy cutting, woolen cutting, denim engraving and cutting.

Application Industry:
Advertisement, arts and crafts, toys, car, mechanism, electron, as well as in trademarks, embroidery, clothing and other industries.
