• Model NO.：PEDB-400B
• Laser Wavelength：Fiber Laser
• Laser Classification：Fiber Laser
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Control：CNC
• Current：AC
• Laser Type：Fiber Laser
• Usage：Metal
• Engraving Machine Type：Fiber Laser Marking Machine
• Gross Weight：55kg
• Transport Package：Wooden Case with Exporting Standard
• Specification：110*110mm,175*175mm,220*220mm
• Trademark：Perfect Laser
• Origin：China
• HS Code：8456110090
• Production Capacity：1000 Sets, Month

Machine TypeFiber Laser Marking MachineLaser SourcePEDB-400  10W  PEDB-400  20WIPG SeriesPulsed, High Energy Ytterbium Fiber LasersMode of operation                                         PulsedPolarization                           randomQ-switched operationOutput power adjustment range10%-100%Nominal average output power W10W20WCentral emission wavelength       1060-1070 nmEmission Bandwidth (FWHM)     < 10 nmLong-term average power instability< 5%Pulse width, (FWHM)                             100 nsLaser switching ON time                       180 μ secLaser switching OFF time               180 μ secPulse Repetition Rate* kHz                   20-80 kHzEnergy per pulse (PRR = 20 kHz)   0.95 mJTypical beam quality, M2                           < 1.8Output fiber delivery length                 3mOperating voltage                                       220VMax. Power consumption       600W
