CNC Sheet Metal Fiber Laser Cutting Machine
Dongguan Glory Star Laser Technology Co., Ltd.- Application：Home Appliance, Environmental Equipment, Petroleum Machinery Manufacturing, Agriculture Machinery, Food Machinery, Aerospace Industry, Automotive Industry
- Cooling System：Water Cooling
- Technical Class：Continuous Wave Laser
- Applicable Material：Metal
- Structure Type：Gantry Type
- Laser Classification：Free Electron Laser
Base Info
- Model NO.：GS-3015
- Laser Technology：Laser Control Fault Cutting
- Model No：GS-3015
- Laser Power：500W,1000W
- Laser Type：Fiber Laser
- Condition：New
- Certification：GS, Ce, ISO9001, FDA, SGS
- Customized：Customized
- Transport Package：Packaged by Plywood
- Specification：CE, SGS
- Trademark：GLORYSTAR
- Origin：China
- HS Code：8456100090
- Production Capacity：5000 Sets,Year
Description
Basic Info.
Model NO. GS-3015 Laser Technology Laser Control Fault Cutting Model No GS-3015 Laser Power 500W/1000W Laser Type Fiber Laser Condition New Certification GS, Ce, ISO9001, FDA, SGS Customized Customized Transport Package Packaged by Plywood Specification CE, SGS Trademark GLORYSTAR Origin China HS Code 8456100090 Production Capacity 5000 Sets/YearProduct Description
CNC Sheet Metal Fiber Laser Cutting Machine
Brief Introduction
Make Metal cutting be Simple and Efficient !
Especially suitable for contact-free cutting, hollowing or drilling of metal sheets in 0.5mm to 10mm, e.g., stainless steel, carbon steel, galvanized sheet, thin aluminum and thin copper etc. Fast and energy-efficient. Total system is high-return with low-investment.
Machine details
Laser Generator
1000W IPG fiber laser generator originally made in Germany
Comprehensive photoelectric conversion efficiency over 30%
Significant power consumption saving, cost saving
Laser Cutting Head
German Precitec laser cutting head
Imported cutting head ensures high precision and fine kerf
Automatic following system adopts double closed-loop design of speed and position
Leap-frog rising supported, highly dynamic response realizes high-speed perforation
Machine Bed Frame
Adopt high strength overall welding structure, cast aluminum cross grider, high temperature annealing treated, finished by imported 12-meter large CNC gantry milling machine. Imported precise ball screw / gear rack and linear guiderail transmission realize high precision, high efficiency and stability.
Machine Driving System
International branded high inertia servo system and gear reducer
Stable movement, reliable, precise and long service life, maintenance free, especially suitable for large size and high speed machines
GS is the most popular mode of fiber laser cutting machine. more than 2000sets of GS fiber laser cutting machines are working in the market. GS enjoys high reputation in the market by its high quality and price ration as well as high stability and efficiency. GS enjoy the honour of well-known product in China as well some overseas market. Now we have GS third generation to appreciate the customers.
Technical parameters
| Model | GS-3015 | GS-4015 | GS-4020 | GS-6015 | GS-6020 |
| Laser Power (W) | 300-2000 (Optional) | 300-2000 (Optional) | 300-2000 (Optional) | 300-2000 (Optional) | 300-2000 (Optional) |
| Working Area (MM) | 3000*1500 | 4000*1500 | 4000*2000 | 6000*1500 | 6000*2000 |
| Total Power Consumption (KW) | 12<30 | 12<30 | 12<30 | 12<30 | 12<30 |
| Dimensions (MM) | 4800*2300*2000 | 6000*2700*2000 | 6000*3200*2000 | 8100*2300*2000 | 8300*3200*2000 |
| Weight (T) | 5 | 5.5 | 6 | 7.2 | 8 |
Service&Supports
1- Fast response to customer's request .
2- One year warranty , lifetime service, and supply parts at low price .
3- Supply the necessary video for assisting customer to intall and utilize the machine, on line assistant.
4- We are able to train the technicians & operators in Glory Laser or in customers' places .
