Metal Tube Laser Cutting Machinehsgq-500W-300150 Fiber Laser Cutting
Zhejiang Holy Laser Technology Co., Ltd.- Application：Home Appliance, Environmental Equipment, Petroleum Machinery Manufacturing, Agriculture Machinery, Textile Machinery, Food Machinery, Aerospace Industry, Automotive Industry, Advertising Industry, Iron, Stainless Steel, Aluminum, Gold, etc.
- Cooling System：Water Cooling
- Technical Class：Continuous Wave Laser
- Applicable Material：Metal
- Structure Type：Gantry Type
- Laser Classification：Fiber Laser
Base Info
- Model NO.：HSGQ-500W-300150
- Laser Technology：Laser Control Fault Cutting
- Laser Power：500W,800W
- Laser Wavelength：1080mm
- Working Size：3000*1500mm
- Lasing Midium：Yvo4
- Min Line Width：Less 0.15mm
- Max Travel Speed：60m,Min
- X Axis Route：3000mm
- Y Axis Route：1500mm
- Z Axis Route：120mm
- Carbon Steel Cutting Thickness：6mm,8mm
- Transport Package：Continer
- Specification：FCC, SGS, FDA, CE, ISO
- Trademark：HOLY LASER
- Origin：Yiwu, Zhejiang, China
- HS Code：8456100090
- Production Capacity：500sets,Year
Description
Laser Power
500W/800W/1000W/2000W
Laser Source
MAX/IPG/Rayco/SPI(It's option)
Laser Type
Fiber Laser
Laser Technology
Germany Technology
XYZ Working area
1500*3000 mm*130mm
Max. Cutting Thickness (Carbon Steel)
6 -8mm
Max. Cutting Speed
0-45 Meters / Min (up to materials)
Laser wavelength
1080nm
Minimum line width
≤0.15mm
Location precision
≤±0.05mm
Re-location precision
±0.02mm
Max. moving speed
60m/min
Supporting Format
PLT, DXF, BMP, AI
Power demand
380V/50Hz
Cooling Way
Water Cooling
Worktable max. load
1000KGS
Transmission Method
Ball Screw Transmission
Table-driven system
Japanese Imported Panasonic Servo Motor & Driving System
Focus Method
Following and Automatic Adjust Focus
Control Method
Offline Movement Control
Control software
Cypcut Laser Cutting Software
Packaging and shipping:
Supplier info:
1.supported by YIWU Government
2. Cooperated with Zhejiang University,update for technology
3.we are the manufacturer,our price are more competitive
4. with 17 years history on reseraching and producing all kind of laser machine
5. Our company welcomes AGENTS all over the world
Certification:
we have independent rights to export and import,andpassed the CE ,FCC ,SGS, TUV and FDA certification.
market and exhibition
Our laser machine have exported to Germony,USA,Britain,France,Italy, South Korea,Japan, India,and so on more than 70 countries and regions, in the market enjoy a high revalution
