• Model NO.：FL9060
• Applicable Material：Nonmetal
• Type：Oscillating Mirror
• Laser Classification：Gaseous Laser
• Engraving Method：Vector Engraving
• Engraving Machine Type：Laser Engraving Machine
• Control：CNC
• Current：AC
• Laser Type：CO2
• Usage：Wood,Acrylic,Leather,Cloth,Paper,Rubber,Plastic...
• Working Area：90*60cm
• Laser Power：60W,90W,100W,130W
• Controller：DSP
• Red DOT Pointer：Have
• Max Cutting Speed：36000mm,Min
• Transport Package：Plywood
• Specification：9060
• Trademark：flying
• Origin：China
• HS Code：8456100090
• Production Capacity：100PC,Month

Basic Info.

Model NO. FL9060 Applicable Material Nonmetal Type Oscillating Mirror Laser Classification Gaseous Laser Engraving Method Vector Engraving Engraving Machine Type Laser Engraving Machine Control CNC Current AC Laser Type CO2 Usage Wood/Acrylic/Leather/Cloth/Paper/Rubber/Plastic... Working Area 90*60cm Laser Power 60W/90W/100W/130W Controller DSP Red DOT Pointer Have Max Cutting Speed 36000mm/Min Transport Package Plywood Specification 9060 Trademark flying Origin China HS Code 8456100090 Production Capacity 100PC/Month

Product Description

Laser engraving cutting machine for wood (FL9060), China leading manufacturer for laser cutting machine,engraving machine


Performance Features:
1. Configure higher quality laser tube with longer lifespan.
2. DSP controlling system, rich functions, can effect engraving on plane, gradient engraving by 360 degree, cutting and drilling holes etc.
3.Owns functions of restoring from power off, continuation on break point.
4. Transmit files directly in CorelDraw, AutoCAD etc.
5.Adopt international linear rail, more precision.

Applicable materials:
Acrylic, ,MDF, Foam, wood, bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and etc

Applicable industries:
advertisement, gift, shoes, toys, computers, garments, model cutting, building, packaging, paper industry, and etc

 Extra Features:

1) Materials can extend through the front and rear doors to allow for a larger work product.2) Work light to help see products during laser processing.3) Red-Dot pointer to help you see the expected laser beam position.4) AutoFocus touch sensor to easily set the right height for best engraving and cutting.5) Parts tray for removing small parts or scrap from under the workbed.6) Fully enclosed laser case yields a class I (user friendly) laser product.

Model	FL9060
Laser-type	10.6um CO2 glass laser tube w/ water-cooling
Laser power	60W/90W/100W/130W
Working area	900 x600mm (35.4 x 23.6 inches)
Max Engraving speed:	0-60, 000mm/min
Max cutting speed	0-36, 000mm/min
Laser output control	1-100% software setting
Location precision	Less than 0.01mm
Highest scanning precision	2500DPI
Operating temperature	0 - 45
Operating humidity	5- 95% non-condensing
Minimum shaping character	English 1.0 x 1.0mm
Graphic format supported	HPGL, BMP, PLT, DST, DXF, and AI ...
Driving system	Stepper(Optional: Servo)
Cooling mode	Water-cooling and protection system
Auxiliary equipments	Exhaust-fans, air-exhaust pipe, air pump, water pump
Controller	DSP
Compatible Software	CorelDraw, AutoCAD, Photoshop, TAJIMA
Slope Engraving	Can be easily designed within the "Grade Engrave" function.
Color separation	Uses color property to set function, speed, and laser power
