• Model NO.：HSCO2-160100
• Power：100W,130W,150W
• Cutting Area：900*1300mm
• Cutting Speed：200mm,S
• Engraving Speed：1000mm,S
• Cooling：Water Cooling
• Usage：Nonmetal Cutting
• Cutting Depth：Acrylic 20mm,25mm
• Machine Size：1770*1310*1070mm
• Structure Type：Desktop
• Transport Package：Wooden Case
• Specification：190*144*116cm
• Trademark：HOLYLASER
• Origin：Zhejiang, China
• HS Code：8456110090
• Production Capacity：500000 Set,Sets Per Year

Technical index

HSCO2-13090

power(W)

100w/130w/150w

laser

CO2 SEALING OFF LASER

cutting speed(mm/s)

≤500mm/s

engraving speed(mm/s)

0-6000

marking scope(mm)

1000*1600mm

(mm)cutting depth(mm)

0-20

location accuracy

0.025

Typ of cooling

water-cooling protection system

Power

AC 220v/50HZ±5%

form surport

PLT,AI,DXF,BMP

parts

rotate fixture ,red light location system ,regrigerating system

1. CO2 Glass sealed laser tube (China famous brand, Good beam mode stability, service time over 6000~10000 hours)
2. Laser Power Good quality and stable power output to extend the laser tube service time.
3. Imported II-VI ZnSe focus lens( High transmittance, good focusing effect and stability
4. DSP control system USB interface, support online/offline work, English language, Adjustable cutting speed and power
5. Japan Stepper motor drive and belt transmission
6. Linear guide rails: Taiwanese made famous
7. Industrial Cooling System The constant water temperature, ensure laser tube a longer service time and high stability
8. Exhaust Fan: Exhaust dust and smoke device
9. Electical Magic Air compressor: The huff protection, protect the laser head focus lens clean
10. Emergency Stop
11. Honeycomb or Slatted worktable optional Honeycomb worktable for cutting fabric leather etc soft material Aluminum knife worktable for cutting acrylic etc hard material
12. Routeway feeding: Allow users of roll material with unlimited length
13. Optional up & down adjustable worktable: Can engrave & cut different height materials
14. The alarm device optional
15. Portable laser cutting machine: With wheels, easy to move and fixed
Woodwork Industry, Textile Machinery, Agriculture Machinery, Environmental Equipment,
Related Models

HSCO2-4040



HSCO2-5040



HSCO2-9060



HSCO2-13090


Company Information

ZheJiang Holy Laser technology Co.LTD has worked hard to become the global leader in manufacturing of laser equipment. All our products has passed the CE, FCC, SGS, TUV and FDA special for American market. 2012, company has obtained 6 patents certificate for computer software technology. Holy laser has been in the laser business since established. We strive to update our technology in the direction of green, environment-friendly and energy saving. review the past Holy Laser won market recognition step by step.looking for ward the future, Holy Laser will continue to dedicate our company mission and ethnic spirit with you to open a new chapter in history.


Service

1, One year guarantee period for product quality. (man made damaged is negotiable).

2, Lifelong maintenance and spare parts supply.

3, Free design of fixtures as customers required.

4, Free training for machines installation and operation of the staffs.

 Contact us

Warmly welcome you visit our factory!!!

Warmly welcome you contact us directly for more information!!!
