• Model NO.：500W
• Laser Classification：YAG Laser
• Type：Laser Spot Welder
• Transport Package：Wooden Case
• Specification：1700*1300*1400
• Trademark：DRIVECNC
• Origin：China
• HS Code：8515809090
• Production Capacity：5000

Basic Info.

Model NO. 500W Laser Classification YAG Laser Type Laser Spot Welder Transport Package Wooden Case Specification 1700*1300*1400 Trademark DRIVECNC Origin China HS Code 8515809090 Production Capacity 5000

Product Description


                              500W YAG LASER WELDING MACHINE

Part 1:Configuration Information
1.Component including Combination chassis + working platform + robotic arm (assembled with combined chassis and working platform) + water chiller + optical fiber + handheld gun.
2.High-end, high-power and large 2-hp chiller, using imported accessories such as Panasonic, Siemens and Schneider.
3.Optical accessories are all first-class brands, standard with 11 original quality crystals, imported quartz lens, welding speed is faster, stronger, and no light decay.
4.Using the best domestic brand high-end dual-lamp metal cavity, greatly enhancing the output power and stability.

Part 2:Technical Parameters


Max laser power	500W
Laser wave length	1064nm
Monopulse Max power	190J
Laser welding depth	0.1-4mm
Pulse width	0.1-20ms
Laser welding frequency	1-100Hz
Laser spot size adjusting range	0.2-3.0mm
Whole power consumption	≤16KW
Power need	380V±10%/ 50Hz /40A
Standard configuration working table	2100*1700mm
Sight positioning	CCD synchronism high definition camera
Laser device vertical travel	≥200mm
Laser device horizontal direction	200-800mm
Length of optical cable	≥5m
Package	1.75*1.24*1.35=2.9m³
Weight	440kg

Part 3.Machine Detail Introduction


Part 4. SS Letter sample show
