355nm UV Laser Engraving Machine Low PriceShenzhen Dapeng Laser Technology Co., Ltd.
- Application：Leather Industry, Domestic, Carpentry, Printing & Packaging, Construction Industry, Molds & Dies, Crafts Industr, Advertising Industry, Manufactury
- Cooling System：Air Cooling
- Technical Class：Pulse Laser
- Automatic Grade：Automatic
- Applicable Material：Nonmetal
- Type：Oscillating Mirror
- Model NO.：UV-3,5,7,10
- Laser Classification：UV Laser
- Engraving Method：Vector Engraving
- Markable Material：FPC,Glass,Plastic,Silicone,LCD,TFT,etc
- Transport Package：Wood
- Production Capacity：3000 Sets,Year
UV laser marking machine, using the 355nm UV laser research and development and, using three order intracavity frequency doubling technology, into the international advanced technology, high energy ultraviolet photons direct damage many nonmetallic materials surface molecules, molecules from the object, in this way will not produce high quantity of heat, ultraviolet laser gathering spot minima and processing of almost no heat effect, therefore is called cold processing, so it can be used to special material ultra fine marking and engraving.
|Laser type||ultraviolet green|
|Standard engraving range||100mm*100mm|
|Optional marking range||50mm*50mm,150mm*150mm, 180mm*180mm|
|Engraving speed||less than or equal to 10000mm/s|
|Outline dimension (W*D*H)||68*65*145cm|
|Power demand||Ac220V + 10%.50Hz-60Hz.5Amp|
|Cooling mode||Air Cooling|
|Operating temperature:||10-35 DEG C|
Working principle and characteristics:
Dapeng laser and UV play labeling machine series products into the international advanced technology, high energy ultraviolet photons direct damage many nonmetallic materials surface molecules, molecules from the object, in this way will not produce high quantity of heat, ultraviolet laser gathering spot minima and processing almost no heat affected, therefore is called cold processing, so it can be used to special material ultra fine marking and engraving.
1. Short UV laser wave length, smaller focused spot, can realize ultra fine marking;
2. is cold processing, small heat affected zone, avoid damage to materials to be processed, high rate of finished products
3. applicable materials widely, make up the deficiency of the infrared laser processing capacity;
4. using high-speed digital galvanometer marking speed, high efficiency, high precision;
5. without supplies, use cost and maintenance cost is low; the performance is stable, long-term operation.
UV laser light spot is very small, and there is almost no heat affected, so it is called cold processing, which is suitable for special materials, super fine marking and engraving. Mainly used for ultra precision machining of the high-end market, cosmetics, medicines, food and other polymer materials of the surface of the packing bottle marking; flexible PCB board marking, dicing; silicon wafer micro hole, blind hole processing; LCD glass two-dimensional code marking, glassware play standard, metal surface coating removal, plastic buttons, electronic components, communication equipment.
Flexible and convenient operating system:
User friendly operation, equipment operation stability is good; the special control software can be compatible with AutoCAD, CorelDRAW, Photoshop and other softwares output; can realize text symbols, graphics, bar code, two-dimensional code, serial number and so on automatic editing and modification; support PLT, PCX, DXF, BMP, JPG and other file formats can be used directly TTF font; CCD automatic identification tracking and positioning;
Working environment requirements:
1. environmental temperature requirements at 10-35 DEG C, air conditioning requirements;
2. temperature requirements for < 60%. No condensation, should install dehumidifier;
3. power supply requirements: 220V; 50HZ/60HZ;
4. power supply fluctuation: + 15%, grid wires meet international requirements. Area voltage amplitude of 15% or more, should install the electronic type automatic voltage regulator, stabilizer;
5. shall be installed near the equipment without strong electromagnetic interference. Around the installation to avoid a radio transmitter station (or trunk);
6. Foundation: less than 50Um; the amplitude of vibration acceleration: less than 0.05g. Avoid a large number of press and other equipment in the vicinity of the press;
In the equipment space requirements to ensure smokeless clean, avoid metal polishing and grinding dust serious working environment;
7. air pressure: 86-106kpa
In some environment should be installed anti-static floor, strengthen shielding;
Exergy cooling circulating water quality has strict requirements, require the use of pure water, deionized water or distilled water, can not use of water, mineral water, etc. liquid with high metal ion or other minerals.
Our core advantages:
1. Usually have 50 units of laser marking machine(Fiber, CO2, UV, Mopa) in stock, lead time 3-5 days.
2. Sold 4500 units of laser machines in China market in 2017, with reasonable price.
3. Fiber Laser cutting machine, (700W, 1000W, 1500W+ laser cutter), usually sell 30 units/month in China.
We are looking for distributor. Price is more competitive.
