CNC Laser Manufacture 500W 750W 1000W 2000W Metal Fiber Laser Cutting Machine Fiber Laser Cutter with Raycus
Jinan Senke CNC Machine Co., Ltd.- Application：Home Appliance, Aerospace Industry, Automotive Industry, Advertising Industry, More Work
- Cooling System：Water Cooling
- Technical Class：3 Axis or 4 Axis
- Applicable Material：Metal
- Structure Type：Desktop
- Laser Classification：Raycus Fiber Laser Source
Base Info
- Model NO.：SKL-1530FB
- Laser Technology：Fiber Laser Cut
- Working Area (X*Y)：1500*3000mm
- Body Structure：Thicken Steel Made
- X, Y Structure：Rack and Pinion
- Rails：Taiwan 25 Square Rails
- Z Structure：Taiwan Tbi Ball Screw
- Max Moving Speed：60000mm,Min
- Xyz Traveling Positioning Accuracy：+-0.01mm
- Fiber Power：Raycua 500W Fiber Power
- Voltage：380V,3phase,Customized
- Drive Type：Schneider Servo Motors&Drivers
- Working Dictate：Working Dictate
- Operating System：Handheld DSP Control System
- Auto Oil Lubricator：Yes,Included
- Wire Protect：Wire Protect
- Fiber Metal Cutter：Yes
- Transport Package：Standard Export Plywood Wooden Box
- Specification：1500*3000mm
- Trademark：SENKE
- Origin：China
- HS Code：8456110090
- Production Capacity：200sets,Month
Description
ModelSKL500F-1530Working area (X*Y)1500*3000mmBody structureThicken steel madeX, Y Structurerack and pinionrailsTaiwan 30 square railsZ StructureTaiwan TBI ball screwX, Y Resolution<0.01mmMax Moving Speed60000mm/minMax Engraving Speed40000mm/minXYZ traveling positioning accuracy±0.01mmXYZ repositioning accuracy±0.01mmSpindle powerRaycua 500W fiber powerVoltage380v/3phaseDrive typeSchneider servo motors&driversDriverSchneider servo driversWorking DictateG CodeOperating systemhandheld DSP control systemAuto oil lubricatorYes,includedWire protectYes,includedRunning EnvironmentTemperature: 0ºC~45ºCpackageExport wooden boxAfter packed size4.7*2.25*1.89MG.W4000KGS
