High Quality 80W 100W 130W 150W CO2 Laser Engraving Machine for Wood Acrylic

Perfect Laser (Wuhan) Co., Ltd.
  • Application：Leather Industry, Advertising Industry
  • Cooling System：Water Cooling
  • Technical Class：Continuous Wave Laser
  • Automatic Grade：Automatic
  • Applicable Material：Nonmetal
  • Type：Flat-Plate

Base Info

  • Model NO.：PEDK-160100
  • Laser Classification：Fluid Laser
  • Engraving Method：Lattice Engraving
  • Engraving Machine Type：Laser Engraving Machine
  • Control：CNC
  • Current：AC
  • Laser Type：CO2
  • Usage：Plastic, Leather Wood
  • Laser Power：100W
  • Working Area：1000×600mm
  • Lead Time：7-10 Working Days
  • Water Chiller Model：Cw-3000, 5000 5200
  • Software：Lasercut Rd
  • Transport Package：Export Sea-Worthy Packing or Air-Worthy Packing
  • Specification：ISO 9001 & CE
  • Trademark：Perfect Laser
  • Origin：China
  • HS Code：845610
  • Production Capacity：5000 Sets of CO2 Laser Engraver , Year

Description

Working Area 1600x1000mm Laser Power 60w / 80w / 100w / 130w / 150w Laser Type Hermetic and Detached Co2 Laser Tube Engraving Speed 0-60000mm/s Cutting Speed 0-10000mm/s Cutting Thickness 0-25mm acrylic (Others Determined by Materials) Repeat Location Accuracy +/-0.0125mm Driving Mode: DC0.8A 24V Stepper Motor Position System: Red dot Laser Pointer Interface: USB port transfer Voltage AC220v/50hz or 110v/60hz Machine Power 900w Controlling System CNC Professional Control System Support Graphics Mode BMP,HPGL,JPEG,GIF,TIFF,PCX,TAG,DST, PLT,DXF etc. Cooling Mode CW-3000 Water Cooling (with Protection Function) Auxiliary Devices Exhaust Fan and Exhaust Pipe Cutting Platform Professional Thickening Strip or Honeycomb Work Table Power Control Mode Laser Energy Combining Movement Control System Software Professional Reader Laser Cutting Software Operating Temperature 0-45C Operating Humidity: 5-95% Packing: Wooden Box Guarantee Time: 12 Months for Machine, 3-10 Months for Laser Tube Operation: VCD Training, Engineer Overseas Available Machine Size 1970mm*1480mm*1250mm High Quality 80W 100W 130W 150W CO2 Laser Engraving Machine for Wood Acrylic

Some question:
The exact material you want to cut? (Acrylic, Wood, Leather, Paper, , , , etc)
The cutting depth on above materials? (Like, 3 mm, 5 mm, 7 mm, 15 mm...)T
He working area you demand? (max dimension of material, width*length, 400*300mm, 1300*900 mm, 1300*2500mm...)
