20W Metal Fiber Laser Marking Machine Laser Engraving Machine
Dongguan Mactron Technology Co., Ltd.- Laser Visibility：Visible
- Applicable Material：Metal
- Cooling System：Air Cooling
- Technical Class：Laser Marking
- Laser Wavelength：Fiber Laser
- Laser Classification：Laser Marking
Base Info
- Model NO.：MT-FP20
- Production Capacity：200 Sets,Month
Description
Model
MT-FP10
MT-FP20
MT-FP30
Work Area(MM)
70X70-200X200(Customization)
Laser Power
10W
20W
30W
Laser Pulse Frequency
20KHz-80KHz
Wavelength
1064±10nm
Beam Quality M2
<1.4
Min Line Width
0.02mm
Min Character
0.2mm
Marking Speed
≤8000mm/s
Marking Depth
≤0.5mm
Repeat Precision
±0.01mm
Power Supply
220V(±10%)/50Hz/4A
Gross Power
<500W
Laser Module Life
100000h
Cooling Style
Air Cooling
System Composition
Control System ,Industrial Computer,Working Table
Working Environment
Clean and Dust Free
Operating Temperature
10ºC-35ºC
Humidity
5% to 75% (Free of Condensed Water)
Power
AC220V, 50HZ, 10Amp Stable Voltage
Warranty
12 Months
Feature Of Fiber optic laser marker machine For Steel
1)Low consumption,non-toxic,no pollution,high performance price ratio.
2) Imported isolator for protection of the fiber laser generator to increase the stability and prolong the laser life.
3) much better than the traditional laser marking machine.
4)Free from maintance, long working life, small size, suitable for any working environment
Applicable Materials:
suitable for all kind of metal, industrial plastic, electroplates, metal-coated materials, rubbers, ceramics and so on.
Applicable Industry:
widely used in food and beverage,pharmaceutical,tobacco,leather,packaging,building
Products Detail:
Sample
