• Model NO.：PE-W300II
• Model：PE-W300II
• Single Pulse Energy：90j
• Pulse Width：0.3-20ms
• Wavelength：1064nm
• Max. Output Power：9kw
• Adjusting Facular Size：0.2-2mm
• Electrical Source：220V,50Hz,40A
• Transport Package：Compound Wooden Cases
• Specification：CE, ISO
• Trademark：Perfect Laser
• Origin：Wuhan, China
• HS Code：8515809090
• Production Capacity：2000 Sets

Basic Info.

Model NO. PE-W300II Model PE-W300II Single Pulse Energy 90j Pulse Width 0.3-20ms Wavelength 1064nm Max. Output Power 9kw Adjusting Facular Size 0.2-2mm Electrical Source 220V/50Hz/40A Transport Package Compound Wooden Cases Specification CE, ISO Trademark Perfect Laser Origin Wuhan, China HS Code 8515809090 Production Capacity 2000 Sets

Product Description

                      Dual Path Fiber High Frequency Laser Welding Machine with Ce

Applicable Industry
Laser welding machine is used for making a variety of stainless steel letter, LED luminous characters, AD Logos, signs and other fast welding.Logo making, fine word production, metal word production, Copper factory, advertising production company, and so on.



Product Introduction

It can realize high efficiency, precision, reliable and qualified automatic production by robot, diode laser, and temperature feedback system (optional). Input processing position and other figures or programs needed, laser can be coupled by fiber and diode laser, this real-time intelligent temperature feedback system can be assembled.



Product Features

1. Constant temperature on soldering spot
2. Easy to set soldering temperature, directly input the figure, without any more experiments to prove.
3. Temperature of soldering point can be continuously adjusted from 100-600 ºC
4. Temperature controlling accuracy within 5 ºC
5. Coaxial CCD imaging, real-time monitoring of soldering spot
6. Local heating with least heat influence on the surroundings.
7. Easy to set processing program, convenient for operation.
8. Optical coaxial of the laser output, the CCD monitor, and the temperature feedback, avoided complicated adjustment and calibration, perfectly solved the superposition of the soldering, guiding, and the imaging spot
9. Continuous gradient heating can be realized by programmable software adjustment.
10. Perfect soldering effects, with full and constant soldering spot.
11. Advanced automation. You can watch the processing imagine while it shows on CCD. You can also add automatic visual identifiable alignment system to realize automatic production.
12. Non-contact processing, without mechanical extrusion to the soldering spot.
13. Accurate soldering, beam spot can be as fine as micron, soldering time can be controlled by program, and the soldering accuracy is much higher than traditional processing way.
14. Fine laser beam replaces iron head, which is easy to solder when there are obstacles on the surface of the soldering point.



Applications

It is suitable for PCB point soldering, metal, non-metallic materials soldering, plastic welding, and other applications of sintering and heating, as well as automatic production on special soldering spot processing in pipeline production. For its features of real time and accurate temperature-control on target soldering points, it is specially suitable for processing high sensitive materials, which needs high precision soldering.



Training, Commissioning & Start up of Machine

1. We will supply with the machine Operation Manual and Training CD in English version for: Installing and operation, including introduction for the composing of equipment, working principle of equipment, common knowledge of computer, controlling principle of electronic devices, daily maintenance measures of equipment. Personal demonstration for installation, adjusting and operation of equipment, and the computer. Common malfunction eliminating measures, etc.

2. We will supply Instruction for simple troubleshooting of the machine when dispatching, which can help you dealing with the common problems happened unluckily. Also, one set of "Instruction Book", "Operation Manual" and "Training Video Disk" for machine/software will be sent to you along with the machine, which could be easily understood and friendly handled by you and your customers.

Quality Guarantee Services and After-sale Services

1. The guarantee period of quality shall be 12 months counting from the date on which the commodity arrives at the port of destination.

2. Except the damage artificially and laser crystal rod and laser lamp, we are responsible for offering the fittings free of charge during the guarantee period, while it is preferred you send the damaged fittings to us by courier with your charge for our testing, after confirming damage, we will send back the alternative fittings to you. After the guarantee of quality period, the parts required repairing or change, if any, shall be paid.

3. When you meet some complicated problem and online-support can not solve it, we can offer Door-Visiting Service. If our engineer to assemble or/and maintain or/and adjust the machine is/are required, we shall assist to deal with the visa formality and prepaid traveling expenses and accommodation to us during the business trip and the service period before their dispatch. And you can arrange for the translating person for the service engineer during their service period. Or you can send your engineer to China. We will offer long-term technical training to him for free.


Remark
1. Payment Terms: T/T before delivery.
2. Production Lead Time: 7-15 working days after receipt of the advance payment.
3. Delivery Method: By sea (please indicate the destination port).
4. Packing: Compound wooden cases comply with international exporting standard.
