• Model NO.：J-9060
• Laser Classification：Solid Laser
• Laser Technology：Laser Control Fault Cutting
• Transport Package：Plywood Case
• Specification：135x94x59cm
• Trademark：Refine
• Origin：China
• HS Code：8479
• Production Capacity：1000 Set,Sets Per Month

Basic Info.

Model NO. J-9060 Laser Classification Solid Laser Laser Technology Laser Control Fault Cutting Transport Package Plywood Case Specification 135x94x59cm Trademark Refine Origin China HS Code 8479 Production Capacity 1000 Set/Sets Per Month

Product Description

9060 60w 80w cut engrave co2 laser machine wooden toys making laser machine



The laser machine could engrave :
Acrylic ,crystal ,cloth,stone,bamboo,paper,plastic,rubber stamp,double color ,glass ,rubber ,plywood,leather,fabric,


The laser machine could cut:
Acrylic,fabric,bamboo,paper ,plastic,rubber stamp,double ,color plate,cloth ,plywood ,leather,wood .


Machine	Parameter
Machine Name	9060 60w 80w cut engrave co2 mini laser machine wooden toys making laser machine
Parameter	Laser type
Laser type	Hermetic Co2 glass tube
Driving system	Stepper motor
Laser power	60W/80W/100W/130W/150W/180W(Optional )
Total  power	≤2000W
Working area	1300*900mm
Max moving speed	0-3000mm/min
Worktable Location precision	±0.1mm
Mini shaping character	Chinese character,2*2mm ,English Letter 1*1mm
Resolution ratio	≤1000DPI
Contronl configuration	Qiancheng controlling ,Ruida controlling (Optional )
Data transfer interface	USB (Offline )
System environment	Windows 2000/Windows XP /Win 7
Cooling Way	Water cooling and protection system
Compatible software	Coredraw, Auto CAD
Cutting thickness	0-20mm(depends on different materials)
Color separation	Separation of cutting up to 256 colors
Operating temperature	0-45ºC
Operating humidity	5-95%
Machine dimension	L1720*W1310*H1050mm
Net weight	300KG
Gross weight	450KG

If you want to know whether the machine can work on your material, please let us know the following information:

1. What materials do you want to engrave or cut?

2. What's the max. size of the materials? (Length*Width*Thickness)

3. We can recommend one for you, or we can customize according to your requirements.

Applicable Materials For Reference:

Material	Engraving	Cutting	Material	Engraving	Cutting
Natural Wood	√	√	Paper	√	√
Acrylic	√	√	Mylar	√	√
Glass	√	×	Pressboard	√	√
Double Color Plate	√	√	Rubber	√	√
Bamboo	√	×	Plywood	√	√
Cloth	√	√	Plastic	√	√
Leather	√	√	Ceramic	√	×
Marble	√	×	Coated Metal	√	×
Stone	√	×	Other Non-metallic	√
