• Model NO.：VLM
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Source Brand：Raycus,Ipg
• Marking Speed：120m,Min
• Control System：Bjjcz
• Driving System：Stepper
• Laser Power：20W,30W,50W,100W
• Key Selling Points：Automatic
• Power Supply：220V,50Hz
• Transport Package：Standard Export Wooden Box
• Specification：110*110mm,200*200mm effective working area
• Trademark：VMADE CNC
• Origin：China
• HS Code：8456110090
• Production Capacity：100sets,Month

Laser PowerRaycus 20WRaycus 30WRaycus 50WRaycus 100WPulsed fiber laserP20QBP30QBP50QBP100QWavelength(nm)  1060~10851060~10851060~10851060~1085PolarizationRandomRandomRandomRandomOptical isolatorYesYesYesYesNominal average output power (W)≥20≥30≥50≥100Single pulse energy (mJ)1@20kHz1@20kHz1@20~50kHz1@20~100kHzBeam quality(M2 )<1.5<1.5<1.5≤1.6Beam Diameter(mm)6~86~86~86~8Pulse duration(ns)<120@20kHz<120@30kHz90-150@50kHz50~130@100kHzPulse repetition rate(KHz)20 - 6030 - 6050-10020 - 200Output Power Tunability(%)10-10010-10010-10010-100Output Fiber Cable length(m)2.02.02.02.0Working voltage(VDC)24±124±124±124±1Power consumption(W)200@20ºC300@20ºC340@20ºC450@20ºCCoolingForced Air CooledForced Air CooledForced Air CooledForced Air CooledDimension W×D×H(mm)215×286×95215×286×95260×391×120396×360×123Operating temperature(ºC)0~400~400~400~40Store temperature(ºC)-20~60-20~60-20~60-20~60Operating Humidity(%)≤80%≤80%≤80%≤80%Marking FormatGraphics, text, bar codes, two-dimensional code, automatically marking the date, batch number, serial number, frequency, etc.Graphic Format SupportedBMP, JPG, GIF, TGA, PNG, TIF, AI, DXF, DST, PLT, ETC.Sample show

laser marking machine are used to mark logo, numbers, code, characters, letters and graphs on different kinds materials, such as stainless steel, aluminum, plastic, wood, silber, gold and so on. As fiber laser beam is very thin and powerful, the machine can do non-contact high accuracy marking which will not destroy the surface of objects.

This machine is widely applided in electronics, apparatus and meters, instrument, hardware tools, automobile, machanical parts, daily necessities, jewelry rings, food packages etc.VMADECNC Factory&Packge
Industry 4.0, VMADE CNC machine co.,ltd is committed to providing basic equipment and personalized intelligent solutions for future industrial production, providing customers with stable and efficient intelligent equipment experience and supply sales to production to after-sales services. Help companies improve productivity and bring more profits.

Customer Visit

FAQ
Q: How can I choose the most suitable machine?

A: In order to recommend you the most suitable machine model, please let us know the following details: 1.What is your material? 2.The size of material? 3.The thickness of material?

Q: This is the first time I use this kind of machine, is it easy to operate?

A: A manual is already included in our product packaging,we also provide 24/7 telephone support to our customers and offer a life time warranty.Jinan Vmade as the largest laser manufacturing factory, we have free installation for optical fiber laser machine in addition to the operating instructions door-to-door free installation services we also provide professional engineers, to provide you for free door-to-door training instruction, so please be assured use

Q: Why choose agent and OEM?

A: The minimum order is 1 set machine, if you order more one time, the price will be better,Jinan Vmade focus on laser research and development production of 14 years,have 31 national patents, It is the largest fiber laser cutting machine, engraving machine and marking machine manufacture in northen of China,we have advanced technology, quality certification CE, ISO 9001, and FDA. products are exported to more than 100 countries and areas, as a focus on laser industry manufacturers, not only can give you a good quality assurance, but also can offer you a good price.
