• Model NO.：CKD-PLUV-10, V21.07
• Applicable Material：Nonmetal
• Laser Classification：Semiconductor Laser
• Engraving Method：Vector Engraving
• Material Example -1：Glass, Acrylic, Ceramic, Plastics and So on
• Material Example -2：Monocrystalline Silicon Chip, IC Grain, Sapphire
• Shipping Date：3-7 Work Days After Payment for Standard Type
• Cooling Mold：Water-Cooling
• Transport Package：Wooden Box
• Specification：CE passed, Europe, Asia, America Standard
• Trademark：CKD LASER
• Origin：Shenzhen, China
• HS Code：8486204900
• Production Capacity：20 Set,Month

Basic Info.

Model NO. CKD-PLUV-10, V21.07 Applicable Material Nonmetal Laser Classification Semiconductor Laser Engraving Method Vector Engraving Material Example -1 Glass, Acrylic, Ceramic, Plastics and So on Material Example -2 Monocrystalline Silicon Chip, IC Grain, Sapphire Shipping Date 3-7 Work Days After Payment for Standard Type Cooling Mold Water-Cooling Transport Package Wooden Box Specification CE passed, Europe/ Asia/ America Standard Trademark CKD LASER Origin Shenzhen, China HS Code 8486204900 Production Capacity 20 Set/Month

Product Description

Function of CKD-PLUV-10, V21.07:

1. Cut plastic, thin glass, paper and so on.
2. Surface peeling.
3. Marking logo, series number, QR code, bar code, bit map (photo / picture) on almost material, including glass, PCB, PVC, PC, leather, wood, stone, jade and so on.
4. Support file of ai, plt, dxf, dst, svg, nc, g, jpg, png, text, and excel.
5. Automatically jump number and generate code.

 Advantage CKD-PLUV-10, V21.07:

1. Portable and big power of 10W UV.
2. Independent combination: can load kinds of devices, such as motorized X-axis, Y-axis, Z-axis, R-axis or manual X, Y, Z.
3. Co-work with your equipment: can be installed on food machine, packing machine, automobile accessory machine and so on.

 * Optional marking scope:100*100/150*150/200*200mm * Water-cooling  * Support 220V, 50Hz or 110V, 60Hz.
What should I install after receiving this machine? Easy three steps:

1. Install on Z-axis column on base board and laser source on Z-axis.
2. Water in chiller and link to laser source.
3. Install marking software in your computer.

Optional devices: Position bar: CKD-PB01, for fixing material and mark on the same location on material.
Rotary for jewelry: CKD-RF00-50, chuck diameter is 50mm
Rotary for big material: CKD-FR01-80H, chuck diameter is 80mm
Manual X-Y table: CKD-MT2D, for slightly moving location
Cutting fixture: CKD-TMFG, for clapping thin material during cutting or engraving, to avoid transformation
Laser protect goggle: CKD-LP01, 200-450 & 800-2000nm multi-wavelength protection, OD4+.
  The marking software is EzCad2, support Windows 7/10, with languages of Chinese, English, Japanese, and Korean.
Optional LED focus tools, built-in galvanometer (marking head) or not.

Configuration:

Model	CKD-PLUV-10
Version	V21.07
Laser source	UV laser, 10W
Marking scope	Optional: 100*100/150*150/200*200
Marking software	EzCad2
Cooling model	Water-cooling
Electricity	Optional: 220V, 50Hz or 110V, 60Hz
Expand function	Optional: motorized X-axis / Y-axis / Z-axis

How to choose marking scope, are focus tools necessary?
Cutting: 100*100mm
Deeply engraving: 100*100mm
Surface marking / printing: 100*100/150/150/200*200mm, depend on your maximum logo / figure / marking content.
