20"*28" 80W Ruida CO2 Laser Engraving and Cutting Machine for Wood acrylic with Blade Table
Redsail Technology Co., Ltd.- After-sales Service:Online Guidance and Overseas Service
- Warranty:12 Month Warranty
- Application:Leather Industry, Carpentry, Printing & Packaging, Crafts Industr, Advertising Industry
- Cooling System:Water Cooling
- Technical Class:Continuous Wave Laser
- Automatic Grade:Semi-Automatic
Base Info
- Model NO.:X700D
- Applicable Material:Nonmetal
- Type:Flat-Plate
- Laser Classification:Gaseous Laser
- Engraving Method:Lattice Engraving
- Machine Operation:Computerized
- Software:Rdworks
- PC Interface:USB2.0 and USB Disk
- Image Form:Hpgl, BMP, GIF, JPG, JPEG, Dxf, Dst, Plt etc.
- Laser Powe:80W
- Material:Wood,Acrylic
- Working Platform:Blade Table
- Voltage:110~240V,50~60Hz
- Resolution:2500 Dpi
- Max Speed:1200 mm,S
- Machinery Test Report:Provided
- Certification:CE FDA
- Applicable Industries:Hotels, Garment Shops, Building Material Shops
- Video Outgoing-Inspection:Provided
- After-Sales Service Provided:Engineers Available to Service Machinery Overseas
- Transport Package:Woodem Case
- Specification:700*500mm
- Trademark:Redsail
- Origin:China
- HS Code:8456110090
- Production Capacity:2000 Units,Year
Description
Product Description
Product Parameters
Standard Accessories
Optional Accessories
Samples Display:
- FAQ
Q: Do I need two laser machines to engrave and cut separately?
Good day!
A: No, the laser machines we provide are capable of both engraving and cutting. One machine alone can fulfill the two purposes.
Q: Do the laser machines need to be connected to a laptop or desktop computer to work?
A: Yes, either is ok. It supports Windows 10, Windows 2000, Windows XP, Win 7, and other operating systems.
Q: What kind of graphic format does it support?
A: JPG, PNG, BMP, PLT, DST, DXF, CDR, AI, DSB, GIF, MNG, TIF, TGA, PCX, JP2, JPC, PGX, RAS, PNM, SKA, RAW , etc.
Q: How to distinguish laser tubes with different powers and applications?
A: 1. Laser tube length (relatively speaking, the longer, the bigger)
2. Laser tube diameter (relatively speaking, the thicker, the bigger)
3. The bigger a laser tube power is, the deeper the machine can cut, but its light spot is bigger. So, it is better to use a machine with a low-power laser tube to engrave, such as 40W, 50W or 60W.
Q: Is it better to increase blow to improve laser processing performance?
A: For some thick materials, it works. But, when carving some other materials, you need to blow less.
Q: How long will it take to learn to operate a laser machine?
A: If you are able to use some basic graphic design software, it will only take a few hours to master the operation. You just need to do some simple tests on different processing materials to know how to set the correct speed and laser power.
Q: Is a laser machine in operation harmful to our bodies?
A: It is not harmful as long as the laser is not exposed directly to skin and eyes.
