• Model NO.：YLP-20, 30, 50M
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Transport Package：Prewood
• Specification：New produces
• Trademark：Dapeng
• Origin：China
• HS Code：84561000
• Production Capacity：200sets,Month

Features:

Easy to Use Automation Features	Sharp, High Contrast, Impact Free	High Speed Galvo Steering
Compact & Fast Set-Up	100,000 Hrs Laser Lifetime	2 Year Warranty
Turnkey System	Permanant Marking	Air Cooled/No Chiller needed
Tunable Pulse Rate	No routine maintenance/No Consumable	Digital I/O for Easy Operation
Red Aiming Pointer/No more mistakes	Solid Aluminum Top Work Surface & Swing Arm Laptop Stand	Portable Tabletop Units to Automated Production Systems Available


Specifications:


Model	YLP-20,30,50
Laser Power:	10W,20W,30W
Wavelenth:	1064nm
Standard Marking Area:	100mm*100mm
Optional Marking Area:	160mm*160mm,200mm*200mm
Marking Speed:	≤7000mm/s
Minimum Line Width	0.02mm
Minimum letter	English: 0.2 x 0.2mm
Marking Depth	0 ~0.5mm
Location precision	≤0.01mm
Resetting positioning accuracy	0.002
Beam Quality	M2:1.2~1.8
Electrical Requirements:	Ac220V±10%.50HZ.5Amp
Cooling mode	Air cooled
Scan Head	High Precision Digital Scan Head
Unit Power	<0.5kw
Operational Temp Range	10-40C
Operational Humidity Range	5%-75%, Non-condensing
Warranty:	2 years on laser source
Dimensions:	25*60*80MM
Net Weight	38KG



Software:

True Type Fonts	Single Stroke Fonts	Elliptical Text
Sequential Serial Numbers	Customizable Auto Dating	Barcodes
QR Codes and Data Matrix	UID Wizard	Logos
Photo Quality Images - JPG, TIF, GIF	Corel Draw, Adobe Illustrator	Raster Graphics
Vector Graphics	CAD Files



Applications:

We offer Fiber Laser Marking Machine with following applications:
l         Laser marking of metal & non-metal material and products: Stainless steel, gold, silver, copper, aluminium alloy, hardware, tools, acrylic, ceramics, plastics, organics, thermo-elastomer rubbers, paper and others
l         Hall marking on Gold
l         Automotive & Engineering Industries
l         Electronic industry: Capacitor, inductor, PCB, IC, connector, control panel and other  instruments
l         Others: Cosmetics, food package, bottle, gift, advertisement & sign crafts, craft & gift making

We also provides laser sources and spare parts to the laser machine manufacturers in China and surrounding countries.

Materials:

Stainless Steel	Steel	Aluminum, Carbide
Nickel	Titanium	Cast Iron
Chrome	Painted Metal Alloys	Multi-Coated Metals
Plastics/Rubber	Backlit Buttons	Polycarbonate
PVC	Composites	Many more materials



Specifications:
 Model   CO2-20,30,50HLaser Power:10W,20W,30WWavelenth:1064nmStandard Marking Area:100mm*100mmOptional Marking Area:160mm*160mm,200mm*200mmMarking Speed:≤7000mm/sMinimum Line Width0.02mmMinimum letterEnglish: 0.2 x 0.2mmMarking Depth0 ~0.5mmLocation precision≤0.01mmResetting positioning accuracy0.002Beam QualityM2:1.2~1.8Electrical Requirements:Ac220V±10%.50HZ.5AmpCooling modeAir cooledScan HeadHigh Precision Digital Scan HeadUnit Power<0.5kwOperational Temp Range10-40COperational Humidity Range5%-75%, Non-condensingWarranty:2 years on laser sourceDimensions:25*60*80MMNet Weight38KG


Software:True Type FontsSingle Stroke FontsElliptical TextSequential Serial NumbersCustomizable Auto DatingBarcodesQR Codes and Data MatrixUID WizardLogosPhoto Quality Images - JPG, TIF, GIFCorel Draw, Adobe IllustratorRaster GraphicsVector GraphicsCAD Files


Applications:

We offer Fiber Laser Marking Machine with following applications:
l         Laser marking of metal & non-metal material and products: Stainless steel, gold, silver, copper, aluminium alloy, hardware, tools, acrylic, ceramics, plastics, organics, thermo-elastomer rubbers, paper and others
l         Hall marking on Gold
l         Automotive & Engineering Industries
l         Electronic industry: Capacitor, inductor, PCB, IC, connector, control panel and other  instruments
l         Others: Cosmetics, food package, bottle, gift, advertisement & sign crafts, craft & gift making

We also provides laser sources and spare parts to the laser machine manufacturers in China and surrounding countries.

Materials:Stainless SteelSteelAluminum, CarbideNickelTitaniumCast IronChromePainted Metal AlloysMulti-Coated MetalsPlastics/RubberBacklit ButtonsPolycarbonatePVCCompositesMany more materials
