Enclosed Mini 30W 50 Watt Fiber Laser Marking Machine

JINAN XINTIAN TECHNOLOGY CO., LTD.
  • Laser Source:Racyus,Jpt,Iipg
  • Galvo Head:Sino
  • Lens:100X100mm 4inch,Optional
  • Software:Ezcad2 Ezcad3
  • Control Board:Jcz
  • Rotary Axis:Optional for Round Object Marking

Base Info

  • Model NO.:FC20 FC30 FC50
  • Fume Purifier:Optional
  • Cooling:Air
  • Support Format:Vector and Image
  • Camera:Cyclops Camera Function Optional
  • Autofocus:Optional
  • Support Voltage:110V 220V Optional
  • Plug:USA,Na,European Standard
  • Wroking Area:100X100mm,up to 300X300mm
  • Laser Type:Fiber Laser
  • Transport Package:Plywood
  • Specification:99x62x106cmx154kg
  • Trademark:XT LASER
  • Origin:China
  • HS Code:8456110090

Description

Overview Technical date



Technical IndicatorsNameLaser Parameterslaser sourceRaycus/JPT/IPG(optional)Laser Wavelength1064nmAverage Output Power30wModulation Frequency Range30kHz-60Khz(20w/30w);
50khz-100khz(50w)Galvometer ParametersMaximum Linear Speed7000mm/sResolution12μradRepeatability8μradOptiocal output characteristicsMarking Range110x110mmMinimum Line Width0.01mmMinimum Character height0.2mmCooling SystemCooling MethodAir CoolingSysten PropertyLaser power0.5kw/AC220V(110V optional)LTower height50cm/80cmEnvironment Requirement0-35ºC



Working videos brass markinghttps://youtu.be/bieldrdDPP0Jewelry ring markinghttps://youtu.be/ZSgs1BphpUkJewelry ring cuttinghttps://youtu.be/V2WM4DrAG_Ystainless steel markinghttps://youtu.be/oX7pJrggGgsCarbon steel markinghttps://youtu.be/1L_mpHLIOg4Samples

Fiber laser marker can mark on almost any metal.
It can also cut some thin jewelry plate.
30w cut up to 0.5mm gold/silver/brass.
50w cut up to 1-1.2mm gold/silver/brass.
If thicker than this thickness,it is also ok,but it takes much longer time to do it.

Enclosed Mini 30W 50 Watt Fiber Laser Marking MachineEnclosed Mini 30W 50 Watt Fiber Laser Marking MachineEnclosed Mini 30W 50 Watt Fiber Laser Marking Machine


Detailed Photos

Enclosed Mini 30W 50 Watt Fiber Laser Marking Machine

Packing

Ply-wood case:99*62*106cm,120kg/154kg
