Auto Focus System 3D Fiber Laser Marking Machine for Barcodes Serials Numbers Electronic Components Hardwares

Wuhan HJZ Laser Technology Co., Ltd.
  • Laser Visibility：Visible
  • Applicable Material：Metal
  • Cooling System：Air Cooling
  • Technical Class：Pulse Laser
  • Laser Wavelength：Fiber Laser
  • Laser Classification：Fiber Laser

Base Info

  • Model NO.：HJZ-DB04
  • Type：Optical Fiber Laser Marking Machine
  • Marking Method：Scanning Marking
  • Laser Output Power：20W, 30W, 50W
  • Engraving Speed：9000mm,S
  • Operating Voltage：110-240V
  • Graphic Format Supported：Ai, BMP, Dst, Dwg, Dxf, Dxp
  • Marking Area：110*110mm, 175*175mm, 220*220mm, 300*300mm
  • Certification：Ce.FDA
  • Condition：New
  • Application Material：0.1-2mm
  • Process Material：Metal and Some Non-Metal
  • Delivery Time：1-3days
  • Laser Source：Raycus
  • Lifespan：Over 20, 000hours
  • Warranty：3 Years
  • Control Software：Ezcad Software
  • Name：30W Metal Engraving Machine
  • Transport Package：Standard Plywood Packing for Export
  • Specification：1650X1250X1050MM
  • Trademark：HZJ
  • Origin：Wuhan, China
  • HS Code：84561000
  • Production Capacity：600sets,Month

Description

Laser Source                           Raycus , IPG , Max  IPG SeriesPulsed, High Energy Ytterbium Fiber LasersMode of operationPulsedPolarizationrandomNominal average output power10W - 30W
10W - 50W Central emission wavelength1060-1070 nm ,Q-switched operation Output power adjustment range 10%-100%Pulse Repetition Rate* kHz20-80 kHzEnergy per pulse (PRR = 20 kHz)0.95 mJTypical beam quality, M2<1.8Output fiber delivery length3mOperating voltage220VMax. Power consumption600WNet Dimensions70*20*50cm58*22*50cm 80*38*72cm 143*62*101cmNet Weight44 kgs53 kgs 130 kgsGross Weight60 kgs70 kgs 200 kgsLaser systemScanning Speed0-7000mm/sMarking Speed0-5000mm/sMarking size110mm×110mm (F-theta 160)Spot size≤ 40 micron (F-theta 160)Cooling unitAir cooledPilot laser650nm diode laser, visible red light for marking guideContinuous working time≥16hHumidity45~85% (no condensation)Operating temperature0~40ºCControl unitsLaser Mark (English Version)


Product descriptions :



Auto Focus System 3D Fiber Laser Marking Machine for Barcodes Serials Numbers Electronic Components Hardwares
Auto Focus System 3D Fiber Laser Marking Machine for Barcodes Serials Numbers Electronic Components Hardwares
Auto Focus System 3D Fiber Laser Marking Machine for Barcodes Serials Numbers Electronic Components Hardwares
Auto Focus System 3D Fiber Laser Marking Machine for Barcodes Serials Numbers Electronic Components HardwaresAuto Focus System 3D Fiber Laser Marking Machine for Barcodes Serials Numbers Electronic Components HardwaresFAQ
Q: Are you trading company or manufaurer ?
A: We are factory. And we have been in the laser field for 10 years.

Q: How long is your delivery time?
A: Generally, it will take 3 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q: Do you provide samples? Is it free or extra ?
A: Yes, we could offer the sample for free charge, but customers should pay the courier cost.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment. Contact us :
