Wood Acrylic Leather 13090 CNC CO2 Laser Engraving Machine
Perfect Laser (Wuhan) Co., Ltd.- After-sales Service：Lifetime Technical Support
- Warranty：3years
- Application：Home Appliance, Textile Machinery, Shoemaking Industry, Woodwork Industry
- Cooling System：Water Cooling
- Technical Class：Continuous Wave Laser
- Applicable Material：Nonmetal
Base Info
- Model NO.：PEDK-13090
- Structure Type：Desktop
- Laser Classification：Free Electron Laser
- Laser Technology：Laser Control Fault Cutting
- Engraving Machine Type：Laser Engraving Machine
- Usage：Woodworking
- Power：High Power
- Drive Type：Stepper Drive
- Certification：CE, ISO 9001
- Laser Type：CO2
- Control：CNC
- Support Graphics Mode：BMP, Hpgl, JPEG, GIF, Tiff, Pcx, Tag, Dst, Plt, Dxf etc.
- Voltage：AC220V,50Hz or 110V,60Hz
- Working Area：1300*900mm
- Laser Power：60W , 80W , 100W , 130W , 150W
- Engraving Speed：0-60000mm,Min
- Cutting Speed：0-10000mm,Min
- Cutting Thickness：0-25mm Acrylic (Others Determined by Materials)
- Repeat Location Accuracy：+,-0.0125mm
- Transport Package：Sea-Worthy Packing or Air-Worthy Packing
- Specification：CE, SGS, ISO, TUV
- Trademark：Perfect Laser
- Origin：China
- HS Code：8456110090
- Production Capacity：5000 Sets , Month
Description
Working Area
1300x900mm (4 feet*3 feet) Co2 Laser Cutters
Laser Power
60w / 80w / 100w / 130w / 150w
Laser Type
Hermetic and Detached Co2 Laser Tube
Engraving Speed
0-60000mm/min
Cutting Speed
0-10000mm/min
Cutting Thickness
0-25mm acrylic (Others Determined by Materials)
Repeat Location Accuracy
+/-0.0125mm
Driving Mode
DC0.8A 24V Stepper Motor
Position System
Red dot Laser Pointer
Interface
USB port transfer
Voltage
AC220v/50hz or 110v/60hz
Machine Power
900w
Controlling System
CNC Professional Control System
Support Graphics Mode
BMP,HPGL,JPEG,GIF,TIFF,PCX,TAG,DST, PLT,DXF etc.
Cooling Mode
CW-3000 Water Cooling (with Protection Function)
Auxiliary Devices
Exhaust Fan and Exhaust Pipe
Cutting Platform
Professional Thickening Strip or Honeycomb Work Table
Power Control Mode
Laser Energy Combining Movement Control System
Software
Professional Reader Laser Cutting Software
Operating Temperature
0-45C
Operating Humidity
5-95%
Packing
Wooden Box
Guarantee Time
12 Months for Machine, 3-10 Months for Laser Tube
Operation
VCD Training, Engineer Overseas Available
Machine Size
1970mm*1480mm*1250mm
