Mini Desktop CO2 Laser Engraving Machine 3060 Nonmetal Etching
Jinan Lansen Laser Equipment Co., Ltd.- After-sales Service：Online Service
- Warranty：2 Years
- Application：Leather Industry, Domestic, Carpentry, Printing & Packaging, Construction Industry, Molds & Dies, Crafts Industr, Advertising Industry, Home Use
- Cooling System：Water Cooling
- Technical Class：Continuous Wave Laser
- Automatic Grade：Automatic
Base Info
- Model NO.：LP-C3060
- Applicable Material：Nonmetal
- Type：Flat-Plate
- Laser Classification：Gaseous Laser
- Engraving Method：Vector Engraving
- Worktable：Standard with Honeycomb Worktble
- Power Supply：220V,50Hz , 110V,60Hz
- Control System：High Speed DSP Control System Brand Ruida or Leetr
- Machine Work Software：Rdworks V8 (Ruida)
- Driving System：Stepper
- Plywood Gross Weight：165kgs
- Transport Package：Wooden Boxes
- Specification：113*78*60cm
- Trademark：Lansen
- Origin：China
- HS Code：8456110090
- Production Capacity：300sets,Month
Description
LP-C3060
Working area
300mm*600mm / 11.81in*23.62in (L*W)
Laser power
60w
Laser type
CO2 sealed laser tube, water-cooled
Worktable
Standard with Honeycomb worktble
Engraving speed
0-50000mm/min
Cutting speed
0-30000mm/min
Highest scanning precision
4000DPI
Power supply
220v/50Hz , 110v/60Hz
Min. shaping character
English 1.0 x 1.0mm, Chinese 1.5 x 1.5mm
Graphic.format.supported
BMP, PLT, DST, DXF, AI
Software supported
CorelDraw, PhotoShop, AutoCAD,TAJIMA
Control system
High speed DSP control system brand Ruida
Machine work software
RDWorks V8 (Ruida)
Laser output control
1-100% by setting in the software
Interface
USB 2.0
Driving system
Stepper
Color separation
Yes
Optional part
Red dot pointer
Spare parts
Extra laser tube/Extra 1 lens and 3 mirrors
Package & delievery:
Our 3060 CO2 laser machines package include 3 layers:1, Outside package: polywood case with metal belt.
2, Middle package: We use foam to cover the machine.
3, Inner package: We use waterproof plastick bag to cover all the machine.
