• Model NO.：LC30F
• Laser Wavelength：CO2 Laser
• Laser Classification：Gaseous Laser
• Type：CO2 Laser Marking Machine
• Marking Method：Scanning Marking
• Repeatability Accuracy：0.001mm
• Transport Package：Wooden Case Packing
• Specification：10W,30W,50W
• Trademark：CYCJET
• Origin：Shanghai, China
• HS Code：8456110090
• Production Capacity：500sets Per Month

Basic Info.

Model NO. LC30F Laser Wavelength CO2 Laser Laser Classification Gaseous Laser Type CO2 Laser Marking Machine Marking Method Scanning Marking Repeatability Accuracy 0.001mm Transport Package Wooden Case Packing Specification 10W/30W/50W Trademark CYCJET Origin Shanghai, China HS Code 8456110090 Production Capacity 500sets Per Month

Product Description

Main Features

Laser Marking Printer for Batch Number

1.General machine, adopted back focalization, laser power is controlled by the software and serially adjustable. It is applicable to fine marking on nonmetal materials with low requirements.

2.Adopting CO2 RF laser tube which has excellent performance and long life<20k hours>.

3.Adopting high-speed galvanometer system with high speed, high precision and stable performance.

4.Adopting imported optics lens, low loss, excellent focalization performance.

5.The marking software is mightiness, under WINDOWS interface, compatible with CORELDRAW, AUTOCAD, PHOTOSHOP etc. a variety of software output files. Support PLT, AI, DXF, BMP and other documents, directly using SHX, TTF font. Support automated coding, serial number, batch number, date, bar code and two-dimensional code marking.

Technical Paramete


Model	LC10/ LC30 / LC50
Laser Power	10W/30W/50W
Laser Wavelength	10.64um
Marking Area	100mm*100mm(Standard)
Adjustable Marking Area(Marking Range)	220mm*220mm/300mm*300mm
Marking Depth	≤2mm/≤5mm/≤8mm
Marking Linear Speed	≤10000mm/s
Min Linear Width	0.1mm
Min Character	0.4mm
Repetition Accuracy	±0.01mm
Rated Power Consumption	≤800W
Supply Voltage	100V~240V 50HZ/60HZ
Cooling Ways	Air Cooling
Process Material	Non-metal Materials.
Support Format	PLT, BMP, DXF, JPG, TIF, AI, etc.
Package	Plastic Bag + Wooden Case

Range of Application

Batch Number Laser Marking Printer

Applicable industry: sanitary ware, food packing, tobacco products, medicine packing, medical apparatus and instruments, watches & glassware, auto accessories, electronic hardware
Applicable materials: ceramic, plastic, glass, stone, leather, cloth, bamboo and so on


Components of machine


 Company Profile

CYCJET Shanghai Yuchang Industrial Co., Ltd.-professional for handheld inkjet printer and portable marking solution, located at the center of Changjiang River Delta and Eastern Sea Bright Pearl - Shanghai City. As a high-tech enterprise, our company specialize in the R&D, manufacture and sales of ink jet printer systems, handheld inkjet printer, handheld laser marking machine, portable marking solution, and so on.

Certifications


Exhibition
