High Speed Raycus 30W Optical Fiber Jewelry Laser Marking Machine for Gold Silver Jewelry Pigeon Rings Bracelet Engraving Cutting

JINAN XINTIAN TECHNOLOGY CO., LTD.
  • Laser Visibility:Invisible
  • Applicable Material:Metal
  • Cooling System:Air Cooling
  • Technical Class:Pulse Laser
  • Laser Wavelength:Fiber Laser
  • Type:Optical Fiber Laser Marking Machine

Base Info

  • Model NO.:XTL-FP
  • Marking Method:Scanning Marking
  • Transport Package:Plywood
  • Specification:99x62x106cmx154kg
  • Origin:China
  • HS Code:8456110090

Description

Overview Technical date



Technical IndicatorsNameLaser Parameterslaser sourceRaycus/JPT/IPG(optional)Laser Wavelength1064nmAverage Output Power30wModulation Frequency Range30kHz-60Khz(20w/30w);
50khz-100khz(50w)Galvometer ParametersMaximum Linear Speed7000mm/sResolution12μradRepeatability8μradOptiocal output characteristicsMarking Range110x110mmMinimum Line Width0.01mmMinimum Character height0.2mmCooling SystemCooling MethodAir CoolingSysten PropertyLaser power0.5kw/AC220V(110V optional)LTower height50cm/80cmEnvironment Requirement0-35ºC



Working videos brass markinghttps://youtu.be/bieldrdDPP0Jewelry ring markinghttps://youtu.be/ZSgs1BphpUkJewelry ring cuttinghttps://youtu.be/V2WM4DrAG_Ystainless steel markinghttps://youtu.be/oX7pJrggGgsCarbon steel markinghttps://youtu.be/1L_mpHLIOg4Samples

Fiber laser marker can mark on almost any metal.
It can also cut some thin jewelry plate.
30w cut up to 0.5mm gold/silver/brass.
50w cut up to 1-1.2mm gold/silver/brass.
If thicker than this thickness,it is also ok,but it takes much longer time to do it.

High Speed Raycus 30W Optical Fiber Jewelry Laser Marking Machine for Gold Silver Jewelry Pigeon Rings Bracelet Engraving CuttingHigh Speed Raycus 30W Optical Fiber Jewelry Laser Marking Machine for Gold Silver Jewelry Pigeon Rings Bracelet Engraving CuttingHigh Speed Raycus 30W Optical Fiber Jewelry Laser Marking Machine for Gold Silver Jewelry Pigeon Rings Bracelet Engraving Cutting


Detailed Photos

High Speed Raycus 30W Optical Fiber Jewelry Laser Marking Machine for Gold Silver Jewelry Pigeon Rings Bracelet Engraving Cutting

Packing

Ply-wood case:99*62*106cm,120kg/154kg
