• Model NO.：PEDK-9060
• Condition：New
• Automation：Automatic
• Type for Cutting Machine：Laser Cutting Machine
• Laser Power：60W , 80W , 100W , 120W , 150W
• Engraving Speed：1-60000mm,Min
• Cutting Speed：1-10000mm,Min
• Repeat Location Accuracy：± 0.0125mm
• Engraving Area：900×600mm
• Repeating Location Accuracy：±0.0125mm
• Transport Package：Export Sea-Worthy Packing or Air-Worthy Packing
• Specification：ISO 9001 & CE
• Trademark：Perfect Laser
• Origin：China
• HS Code：8456100090
• Production Capacity：1000 Units, Month

Model
PEDK-4030
PEDK-6040
PEDK-9060
PEDK-13090
PEDK-160100
PEDK-130250
PEDK-130180
PEDK-160260
Working Area
400×300mm
600×400mm
900×600mm
1300×900
mm
1600×1000mm
1300×2500mm
1300×1800mm
1600×2600mm
Laser Power
40W / 50W
50W / 60W
60W / 80W
60W / 80W / 100W / 120W / 150W
Laser Type
Hermetic and Detached Co2 Laser Tube
Engraving Speed
1-60000mm/min
Cutting Speed
1-10000mm/min
Repeat Location Accuracy
± 0.0125mm
Laser Power Controlling
1-100% Manual Adjustment and Software Controlling
Voltage
220V(±10%) 50Hz
Cooling Mode
Water Cooling and Protect System
Cutting Platform
Professional Thickening Strip or Honeycomb Work Table
Controlling Mode
CNC Professional Control System
Support Graphics Formats
BMP, HPGL, JPEG, GIF, TIFF, PCX, TAG, CDR, DWG, DXF
Compatible HPG Order To Support DXF, WMF, BMP, DXT
Power Controlling Mode
Laser Energy Combining Movement Control System
Control Software
Original Perfect Laser's Engraving & Cutting Software
Training
Video Training
Guarantee
12 month Guarantee Period
Remark :
1.Payment terms: T/T, L/C, West Union,Alibaba Escrow.
2. Delivery lead time: 7-10 working days after receipt of the advance payment.
3. Delivery method: by sea or air shipment.
4. Packing: compound wooden cases with exporting standard

Training&Service:
1. 12months Gurantee Period;
2. Free Online Consulting Service
3. Free Operation Tranining in our factory;
4. Detailed Operational Manual &Traning CD in English Version
5. Guarantee of Quality and After Sales-Service:
The guarantee period of quality shall be 12 months counting from the date on which the commodity arrives at the port of destination. Except the artificial damage and wearing parts, we are responsible for offering the fittings free of charge during the guarantee period, but you must send the damaged fittings to us by courier with your charge before we send back the alternative fittings to you. After the guarantee of quality period, the parts required to repair or change, if any, shall be paid.



Please advise us the following information, then we can recommend you the most suitable model, right now, don't hesitate to contact -China Perfect Laser!

1):The exact material you want to engrave/cut? (wood, acrylic, cloth, fabric, leather, rubber, paper, plastic, marble....)

2):The cutting depthon above materials?(max thickness, 3 mm, 6 mm, 15 mm, 20 mm....)

3):The working area you demand? (max dimension of material, width*length, 600*400 mm, 900*600 mm, 1300*900 mm,1600*1000mm...)Working area and laser power can be customized.

4)After cut/engrave, what will be the material used for? (application)

5)Are you an end user or reseller?

Welcome for your inquiry soon.
