• Model NO.：PE-F3015
• Structure Type：Gantry Type
• Laser Classification：Solid Laser
• Laser Technology：Laser Vapor Cutting
• Control：CNC
• Current：AC
• Laser Type：Fiber Laser
• Usage：Metal
• Product Name：Fiber Laser Cutting Machine
• Gross Weight：3000kgs
• Working Area：3000*1500mm, 2500*1300mm, 2000*4000mm
• Power：300W, 500W, 800W, 1000W, 1500W, 2000W
• Voltage：220V,380V,460V
• Leading Time：30 Working Days
• Max. Moving Speed：100m,Min
• Laser Wavelength：1070nm
• Supporting Format：Plt, Dxf, BMP, Ai
• Power Demand：380V,50Hz
• Control Method：Offline Movement Control
• Transport Package：Wooden Case with Exporting Standard
• Specification：ISO 9001 & CE
• Trademark：Perfect Laser
• Origin：China
• HS Code：8456110090
• Production Capacity：1000 Sets, Month

Basic Info.

Model NO. PE-F3015 Structure Type Gantry Type Laser Classification Solid Laser Laser Technology Laser Vapor Cutting Control CNC Current AC Laser Type Fiber Laser Usage Metal Product Name Fiber Laser Cutting Machine Gross Weight 3000kgs Working Area 3000*1500mm, 2500*1300mm, 2000*4000mm Power 300W, 500W, 800W, 1000W, 1500W, 2000W Voltage 220V/380V/460V Leading Time 30 Working Days Max. Moving Speed 100m/Min Laser Wavelength 1070nm Supporting Format Plt, Dxf, BMP, Ai Power Demand 380V/50Hz Control Method Offline Movement Control Transport Package Wooden Case with Exporting Standard Specification ISO 9001 & CE Trademark Perfect Laser Origin China HS Code 8456110090 Production Capacity 1000 Sets/ Month

Product Description

300W 500W 800W CNC Fiber Laser Metal Cutting Machine

(Model: PE-F3015)
Contact: Susie



Fiber laser cutting machine brief introduction:
Perfect Laser, professional CNC Fiber Laser Metal Cutting Machine manufacturers, with advanced cutting machine equipment, first-class technology, quality service, get good reputation in fiber laser cutting machine equipment industry.

In order to meet the needs of customers for cutting metal pipe and sheet, Perfect Laser launched the multi-functional Metal Pipe and Sheet Fiber Laser Cutting Machine(Model:PE-F3015). This cutting machine is adopted the Taiwan famous screw guide, Panasonic servo and drive, the cutting machine can improve the working efficiency greatly. And the pipe diameter of the cutting machine can up to 200mm (can be customized according to customer needs ). Moreover, the cutting machine's unique design with rotary auxiliaries can solve the technical problems for cutting pipes and sheets.

Application:This CNC fiber laser cutting machine can effectively cut pipe, square tube, rectangular tube, oval tube, parallel oval tube, D-tube, and other styles of pipe.
CNC fiber laser cutting machine main processing materials: stainless steel, carbon steel, manganese steel, galvanized sheet, all kinds of alloy plate, rare metals.
CNC fiber laser cutting machine main application industry: sheet metal industry, kitchenware industry, elevator mobile phone industry, advertising industry, chassis cabinet industry, machinery parts processing industry, precision machining industry, automobile manufacturing industry, daily light industry, agricultural machinery, and food machinery industry, hardware bathroom industry, Medical fitness equipment industry
 Fiber laser cutting machine advantages:
* High cutting speed: 2-3 times faster than YAG or Co2 laser
* Long lifetime span: laser source lifetime over 10 years with stable performance.
* High cutting accuracy: Finest laser beam up to 0.01mm
* Low maintenance: Almost totally free of Maintenance
* Most advance cutting machine on the world


 Technical Data:

Name	Metal sheet and pipe fiber laser cutting machine
Model	PE-F3015B 500W (800W1000W2000W)
Maximum run speed	90m/min
Laser Wavelength	1080 nm
Minimum cutting line width	0.1mm
Rated output power	50--2000W
X, Y-axis positioning accuracy	≤±0.01mm
Repeated positioning accuracy of the table	≤±0.01mm
The maximum load of the workbench	800KG
Effective processing format	1500*3000mm
Z-axis travel	120mm
Volume	4.6*2.3*1.8m
Power	12KW
Water cooler	2kw
Electricity power	380v 50Hz±10%
Red light spot position	yes
Auxiliary gas	Oxygen, nitrogen
Pipe type	Round,oval,special-shaped pipe
Pipe Length	3-9m
Diameter	1mm-300mm


 Machine  Details1.The metal laser cutter's controller with a touch screen operating system:

Fiber laser controller installed on the computer.

Ytterbium laser cutting system, automatic optimized cutting path calculation, industrial computer installed software;

Touch screen operation system to control the laser head (adjust the distance between the laser head and metal material); wireless control handle can control the laser cutting head movement trajectory.

The metal laser cutter is adopts Lasermach(USA) and PRECITEC(Germany ) automatic focus laser cutting head (metal sensor) : Laser cutting head nozzle contact metal plate surface, cutting head automatically move up and down, high sensitivity, good stability. No obvious spark phenomenon.

3. The metal laser cutter with 3HP high-power water chillers: adopts a water cooling method to keep the laser head always work in constant temperature(plus or minus 5 degrees), to ensure the stability and fast operation of the laser.

4.The metal laser cutter with Raycus 1000W (IPG1000W) fiber laser generator: photoelectric conversion rate is high, high beam quality, work-life of more than 100,000 hours, no maintenance costs.

5. Universal ball screw and jagged shaped working platform, loading metal material fast, and keeping stable feeding work. jagged platform fixing strip can fix the material to reduce the spark splash when cutting.

6.The cutting machine is adopted by Japan's Panasonic servo motor and drive: improve the cutting speed and stability. Positioning accuracy: ≤ ± 0.05mm; maximum moving speed 90m / min, maximum effective cutting area 1500 * 3000mm. The servo system has excellent dynamic response acceleration characteristics for smooth operation, reliable, no maintenance.

7.Self-service refueling, alarm system, smoke device: Laser cutting machine tracks can automatically be refueled, always ensure track lubrication. laser cutting machine alarm system to remind the situation of the role of the machine. Smoke device can extract the smoke in the cutting process, to protect the working environment.

8.Rotary aids: the unique design with rotary auxiliaries can solve the technical problems for cutting pipe.Need more information please feel free to contact us-Perfect Laser!---Right Now!!
