CO2 Laser Cut Machine Engrave Cutting Machine Factory Wholesale
Beijing Daqin New Universe Electronic Co., Ltd.Base Info
Description
Packing&ShippingPacking material :Wooden case and carton with foam inside so that machine is safe during shipping .
Shipping : Usually are in stock ,can ship within 2-3 days after get payment ,because we need some time to test machine and prepare materials,usually by DHL ,TNT ,FEDEX Or ups .If order big quantity ,can ship by air or sea
Features:
1. Precise Cutting.
2. Fine and smooth edge, no rough selvedge.
3. High-compatibility of materials.
4. On-production production, no swelling inventories.
5. Easy to use.
The entire system is made up of the Daqin mobile screen protector design software and the cutting machine.
Application range: Cutting various model of mobile phone screen protection film worldwide(Brand of newly published mobile phone protection film will be updated in time ), personalized screen protection film of the camera, MP3, MP4, tablet, PC etc.
The Daqin software runs on the computer. Various dimension data of the screen protection film are stored in the Daqin software. Run the software and choose the corresponding data of the screen protection film according to the model and brand, then the chosen data will be output to the Daqin screen protector cutting machine. After that, it will cut out the corresponding shape of the screen protection film with the material of PET, PVC etc. Also, the user can add data of new model of mobile phone screen film.
Special announcement: Daqin automatic screen protector cutting system won TWO national patents, with proprietary intellectual property rights.
Shipping : Usually are in stock ,can ship within 2-3 days after get payment ,because we need some time to test machine and prepare materials,usually by DHL ,TNT ,FEDEX Or ups .If order big quantity ,can ship by air or sea
Features:
1. Precise Cutting.
2. Fine and smooth edge, no rough selvedge.
3. High-compatibility of materials.
4. On-production production, no swelling inventories.
5. Easy to use.
The entire system is made up of the Daqin mobile screen protector design software and the cutting machine.
Application range: Cutting various model of mobile phone screen protection film worldwide(Brand of newly published mobile phone protection film will be updated in time ), personalized screen protection film of the camera, MP3, MP4, tablet, PC etc.
The Daqin software runs on the computer. Various dimension data of the screen protection film are stored in the Daqin software. Run the software and choose the corresponding data of the screen protection film according to the model and brand, then the chosen data will be output to the Daqin screen protector cutting machine. After that, it will cut out the corresponding shape of the screen protection film with the material of PET, PVC etc. Also, the user can add data of new model of mobile phone screen film.
Special announcement: Daqin automatic screen protector cutting system won TWO national patents, with proprietary intellectual property rights.
| Name | Mobile Phone Screen Protector Laser Cutting Machine |
| Model | Daqin screen cutting - DQ- A188 |
| Cutting way | Controled by professional software |
| Cutting Type | Laser Cutting |
| Beam type | CO2(Carbon dioxide beam) |
| Beam power | 40 W |
| Cooling system | Circulating water cooling system |
| Exhausting fume method | Back exhaust |
| Maximum cutting area | 297mm*210mm |
| Cutting precision | ±0.01mm |
| Cutting speed | <50cm/s |
| Drive type | 0.9°Stepper motor |
| Communication interface | USB Print line |
| Operating temperature | 5-45 C |
| Machine size | 83 CM * 50 CM * 25 CM |
| Weight | 32 KG |
| Total Power | 200 W |
| Packing size | 92 CM * 62 CM * 38CM |
| Weight after packing | 45 KG |
| Package | Three layers |
| Shipping way | DHL ,Fedex ,TNT ,UPS ,EMS and so on |
| Advantage | No rough edge and Accurate |
