Low Cost Mold Laser Welding for Stainless Steel Machine for Sale
Perfect Laser (Wuhan) Co., Ltd.- Application：Biomedicine, Electronic Industry, Automotive Industry, Powder Metallurgy
- Technical Class：Continuous Wave Laser
- Control：Automatic
- Power Density：Deep Fusion Welding
- Laser Classification：YAG Laser
- Type：Silicon Steel Sheet Laser Welding Machine
Base Info
- Model NO.：PE-W300M
- Current：Direct Current
- Model：PE-W200,300,400m
- Spot Adjusting Range：0.1-3mm
- Wire Diamter：0.1mm-0.6mm
- Wavelength：1064nm
- Max. Output Power：9kw
- Adjusting Facular Size：0.2-2mm
- Electrical Source：220V,50Hz
- Laser Power：200,300,400W
- Transport Package：Compound Wooden Cases
- Specification：CE, ISO
- Trademark：Perfect Laser
- Origin：Wuhan, China
- HS Code：8462219000
- Production Capacity：2000 Sets
Description
X=250mm,Y=180mm
Table capacity
≤200KG
≤200KG
≤200KG
Machine battery
220V±10%/50/60z
380V±10%/50/60Hz
380V±10%/50/60Hz
Laser type
Nd:YAG pulse xenon lamp
Nd:YAG pulse xenon lamp
Nd:YAG pulse xenon lamp
Spot adjusting range
0.1~3mm
0.1~3mm
0.1~3mm
Peak wavelength
1064nm
1064nm
1064nm
Pulse width
≤20ms
≤20ms
≤20ms
Rated output power
180W
270W
360W
Maximum laser power
200W
300W
400W
Pulse frequency
≤50Hz
≤50Hz
≤50Hz
Laser output focal length
100mm
100mm
100mm
Laser cooling
Water cooling
Water cooling
Water cooling
Monitor
Microscope( rotate360º)
Microscope( rotate360º)
Microscope( rotate360º)
Protective gas
1(argon)
1 (argon)
1 (argon)
Cold water capacity
2700W
3500W
5000W
Wire diamter
0.1mm~0.6mm
0.1mm~0.8mm
0.1mm~1.0mm
Dimension
Main engine
1250*580*1200mm
Chiller
700*500*900mm
Main engine
1250*580*1200mm
Chiller
700*500*900mm
Main engine
1250*580*1200mm
Chiller
700*500*900mm
Power
900*600*700MM
---Remark
1. Payment Terms: T/T before delivery.
2. Production Lead Time: 7-15 working days after receipt of the advance payment.
3. Delivery Method: By sea (please indicate the destination port).
4. Packing: Compound wooden cases comply with international exporting standard.
---My contacting way:
Perfect Laser Co., Ltd. (China)
Contact: Cindy/ Sales Department
Add: HengRuichuangzhi Technology Park, No.13 YangQiaohu Road, Jiangxia District, Optical Village, Wuhan, Hubei, China(430200).
Welcome to contact us for further information!
