• Model NO.：LSD30R
• Laser Wavelength：CO2 Laser
• Laser Classification：Gaseous Laser
• Type：CO2 Laser Marking Machine
• Marking Method：Scanning Marking
• Laser Power：30W
• Laser Type：CO2
• Marking Area：100*100mm
• Laser Source：Yongli Davi Synard
• Transport Package：International Standard Plywood Box
• Specification：158kgs
• Trademark：Lansen
• Origin：China
• HS Code：8456110090
• Production Capacity：300sets,Month

Basic Info.

Model NO. LSD30R Laser Wavelength CO2 Laser Laser Classification Gaseous Laser Type CO2 Laser Marking Machine Marking Method Scanning Marking Laser Power 30W Laser Type CO2 Marking Area 100*100mm Laser Source Yongli Davi Synard Transport Package International Standard Plywood Box Specification 158kgs Trademark Lansen Origin China HS Code 8456110090 Production Capacity 300sets/Month

Product Description

Paper Leather Desktop CO2 RF Laser Marking Machine 30W
 Lansen CO2 Laser Marking Machine, also called Co2 Laser Engraving Machine, namely carbon dioxide Laser Marking Machine. It is capable to mark text, series number, QR code, data, pictures, etc. on almost all non-metal materials, especially suitable for some fields required more precise and higher smoothness. The desktop CO2 laser marker also have cutting ability of thin material like paper fabric.







 Parameters:

Type	LSD30/60/100/150R
Laser power	30W/60W/100W/150W Metal RF tube (China or imported)
Laser Wavelength	10.6μm
Laser Repetition Frequency	≤25KHZ
Making Area	110mm*110mm/200mm*200mm/300mm*300mm
Making Depth	≤0.3mm(adjustable according to materials)
Linear Speed	≤7000mm/s
Min.Line Width	0.1mm
Min.Letter	0.4mm
Repeatable Accuracy	±0.01mm
Gross Power	1.2KW
Electricity Source	220V/50Hz/8A
Cooling System	Air Cooling
Package size/Gross Weight	1030mm*840mm*1010mm/158kg
Suitable for	Nonmetal materials marking or leather cloth quickly cutting

Samples:


Our Survice:
1. 24 Months for Machine
2. 6 Months for equipment outside, such as water pump, fan, air pump,etc.
3. Detailed manual and video to guide the user how to use the machine and maintenance, also supply the specs settings for the speed and power to engrave or cut on various material. Lifely and fast technical guide and solution within 24hours by email and web camera.

Packaging&Delivery
International Standard Plywood Package
Our laser engraving cutting machine with 3 layer package, waterproof film, foam and plywood. They suit ship by sea. Just let us know your city or your local sea port name, we will check sea freight for you reference.

About us:


FAQ:
Q: How can I choose suitable machine?
A: Please communicate with us via inquiry or email, we can guide you. Please kindly tell us:
1) .What work table size you will need?
2).What work you will do?

Q: What's your payment terms? Delivery time and MOQ?
A: We accpet T/T(bank transfer), L/C, Paypal, Western union etc. Usually we need 30% as deposit, balance paid before shipment.
Delivery Time: 3-5 days after payment
MOQ: 1set

Q: If I bought a machine, how could you make it safe while shipping.
A: We have a professtional package suitable for oversea transpotation. Machine will be fixed well in the case.

Q: What's your quality control system?
A: All machines will be tested after finished. We have QC department response for this job. And we already got CE approved.

Q: If I don't know how to use the machine, can you teach me?
A: 1) There is a DVD disc including machine user manual and software user manual c/w machine.
2) Online (skype & phone)
3) Remote desktop software (Teamviewer)
4) Demo Video
