Good Price Top Quality Fixed Static 30W Max Fiber Laser Engraving Marking Machine with CE

Guangzhou Prima Technology Co., Ltd.
  • Laser Visibility：Visible
  • Applicable Material：Metal
  • Cooling System：Air Cooling
  • Technical Class：Pulse Laser
  • Laser Wavelength：Fiber Laser
  • Laser Classification：Solid Laser

Base Info

  • Model NO.：IPS-LF30 S
  • Type：YAG Laser Marking Machine
  • Marking Method：Scanning Marking
  • Part No：IPS-Lf 30 S
  • Laser Power：30W
  • Wavelength：1064nm
  • Overrall Power：Around 300 Watt
  • Power Supply：220V,50Hz,5A,1p
  • Scanning Galvanometer：High Speed Digital Motor
  • Focus System：Two Red Light with Outline Indication
  • Repetition Accuracy：+-0.002 mm
  • Min Linewidth：0.01mm
  • Linear Speed：Around 8000 mm,S
  • Marking Size：70*70mm,110*110mm,175*175mm,300*300mm
  • Weight：80kg
  • Operation System：Android
  • User Interface：15 Inch Industrial Computer
  • Language：English Russian Thailand Korea Arabic Portuguese
  • Transport Package：Wood Carton
  • Specification：60*80*135CM
  • Trademark：IPS
  • Origin：China
  • HS Code：8456110090
  • Production Capacity：1000, Year

Description

Model IPS-LF30 SLaser PowerMore than 30 wattLaser Wavelength 1064 nmLaser Frequency20K HZ-80K HZLinear Speed around 8000 mm/ s or more Marking Size 75*75mm, 150*150mm, 200*200mm, 300*300mm Min Linewidth0.01 mmMin Font Height0.01 mmRepetition Accuracy+-0.002 mmOverall Power Less than 500 WPower Supply 220V/50-60HZ/5A/1PLaser Gun Brand MAX/ RAYCUS/ IPG/ Others  Laser Gun Type Solid-state Fiber LaserScanning System Digital Scanning Galvanometer with high seep motoFocus system  Two Red Light with accurate positionCooling system Built-in Air CoolingIndication SystemInner Outline IndicationFlying System 10.5 inch professional industrial computer based on Android Weight Around 80 KGOverall Dimension60*80*135 CMFile Format SupportSupport file from CORELDRAW,AUTOCAD,PHOTOSHOP directly.  SupportAI,PLT,PCX,DXF,BMPfile.
Support all fonts from windows system. Support automatic coding, serial no, batch no, real time, variable barcode and QR code and databases.
