• Engraving Method：Vector Engraving
• Model：Man-6090
• Working Area：600*900mm
• Laser Power：60W ,80W ,100W
• Engraving Speed：0-64000mm,Min
• Cutting Speed：0-36000mm,Min
• Preposition Accuracy：0.1mm
• Cutting Platform：Blade or Honeycomb Table
• Driving System：Stepper Motors
• Power Supply：AC220V 50Hz
• Transport Package：Wooden Box
• Specification：2000*1600*1250mm
• Trademark：CNMANLASER
• Origin：Shandong
• HS Code：8456110090
• Production Capacity：500 Set,Month

Basic Info.

Engraving Method Vector Engraving Model Man-6090 Working Area 600*900mm Laser Power 60W /80W /100W Engraving Speed 0-64000mm/Min Cutting Speed 0-36000mm/Min Preposition Accuracy 0.1mm Cutting Platform Blade or Honeycomb Table Driving System Stepper Motors Power Supply AC220V 50Hz Transport Package Wooden Box Specification 2000*1600*1250mm Trademark CNMANLASER Origin Shandong HS Code 8456110090 Production Capacity 500 Set/Month

Product Description

Blade Table Engraving CO2 Laser Machine 900*1300mm 600*900mm for Plastic Acrylic WoodProduction :   MAN-6090  Laser Cutting Machine work with 2 sets of co2 laser tube, power supply, cooling system and laser cutting heads, so that the processing

efficiency will be doubled. Dual heads Laser Cutting Engraving Machine is to put the moving control into full play and therefore increase the working

effects of laser processing.

In each aspect, from the software design, mechanical structure to the configuration, the tenet is to serve for the processing to make sure the stability,

precision and speed under the safe and overall quality-management working environment.

There are two working places for this Laser Cutting Machine/Engraving Machine, which can alternate automatically so that the machine can cut while

feeding and the feeding time is greatly decreased.
 Technical Parameter :

Laser type	Hermetic CO2 glass tube
Laser power	80 W/100W/130W/150W (optional)
Driving System	Stepper motor
Power supply	AC220±10% 50HZ/AC110±10% 60HZ
Total power	≤2,000W
Working area	1300*900mm
Max moving speed	0-30000mm/min
Worktable	Up&down worktable/fixed worktable (optional)
Location precision	±0.1mm
Mini shaping character	Chinese Character, 2*2mm, English Letter, 1*1mm
Resolution ratio	≤4500DPI
Control configuration	RUIDA Controlling System
Data transfer interface	USB (offline)
System environment	Windows 2000/ Windows XP /Win 7
Cooling way	Water cooling and protection system
Graphic format supported	files which CorelDraw,Photoshop can identify  (BMP,GIF,JPGE,PCX,TGA,TIFF
Cutting thickness	0-20mm (depends on different materials)
Color separation	Separation of cutting up to 256 colors
Operating temperature	0-45ºC
Operating humidity	5-95%
Cuts off the water supply  the protection	Yes
Machine dimension	2000*1600*1250mm
Net weight	400kg
Optional Parts	High-grade cooling system/imported focus lens/double-head/cylinder rotary .

Details Images :         Advantage :

1.FDA compliant ,CE Certification ensures high quality of our machines.

2.USB Interface,UFlash Disk Supported,Machine will read files from memory stick,you can work even without a PC.

3.Automatic up and down table (Optional).

4.Red dot pointer.Provides a visible laser beam for setting up projects to exactly where the laser will fire.

5.Integrated vacuum table. Hold down thin,warped materials with the Vacuum Hold-down table  by drawing air down through the table .

6.Auto Focus (Optional).Automatically sets the correct table height for focusing the lens to  achieve  the highest detail engraving.

7.Adjustable speed and power on the fly.Test your speed and power settings by adjusting them directly at the laser system.
