• Model NO.：HJZ-DB-03
• Laser Wavelength：Fiber Laser
• Laser Classification：Fiber Laser
• Type：Optical Fiber Laser Marking Machine
• Marking Method：Scanning Marking
• Laser Output Power：20W, 30W, 50W
• Engraving Speed：9000mm,S
• Operating Voltage：110-240V
• Graphic Format Supported：Ai, BMP, Dst, Dwg, Dxf, Dxp
• Marking Area：110*110mm, 175*175mm, 220*220mm, 300*300mm
• Certification：CE.FDA, SGS
• Condition：New
• Application Material：0.1-2mm
• Process Material：Metal and Some Non-Metal
• Delivery Time：1-3days
• Laser Source：Raycus
• Lifespan：Over 20, 000hours
• Control Software：Ezcad Software
• Name：30W Metal Engraving Machine
• Transport Package：Standard Plywood Packing for Export
• Specification：680*950*1400 mm
• Trademark：HJZ laser
• Origin：Wuhan, China
• HS Code：8456110090
• Production Capacity：600sets,Month

Technical parameter

Item  /  Model

HJZ -DB-04  (20/30/50/60/70/100W)

Laser source

Domestic Raycus(Germany IPG/China CAS/MAX/JPT Mopa color marking for optional)

Laser power

20w, 30w, 50w,60w ,70w,100w

Laser type

Fiber laser

Graphic Format Supported

PLT,BMP,JPG,PNG,TIP,PCX,TGA,ICO,

DXF

Marking speed

≤9000mm/S

Max.Marking Depth

≤0.4mm

Laser Wavelength

1064nm

Marking lines

1-10 marking lines(in the marking area)

Minimum line width

0.01mm

Minimum character

0.15mm

Resolution ratio

0.01mm

Graphic format supported

BMP, PLT, DST, DXF, AI

Software supported

TAJIMA, CorelDraw, Photoshop, AutoCAD

Equipment Dimensions

420*320*800mm

Net Weight:

150kg

(different model has different weight,detailed can be confirmed with sellers)

Unit Power

≤500W

Optional Spare Parts

 Rotary/Protection glasses/outside red light/night light and so on.

Training can be processed in the following ways:
1) Workers of customers can come to our factory in Wuhan, China to get the most professional hand-by-hand training.
2) We can send engineers to customers' country and do training for workers in customers' target factory. However, tickets and daily consumption like food and accommodation should be afforded by customers.
3) Remote training through Internet tools like Team-viewer, Skype and other instant communication software.

Guarantee:
We offer free Two-year warranty and durable maintenance&repair support for the purchased machines. Within the warranty time, we are responsible for the cost-free repair once the equipment fail or the machines break down(except human factor and force majeure causes) and we shall offer the replacement parts for free(except consumed parts). During the non-warranty time, we just charge the flat cost based on actual cost of repair.
