China Big Size 1300X2500mm Flatbed 500W CO2 1325 Laser Cutting CNC Laser Cut Machine for Acrylic/ MDF /Plywood /Leather/ Clothing /Wood
Jinan Laser Max Machinery Tech Co., Ltd.- After-sales Service：Online
- Warranty：3years
- Application：Home Appliance, Environmental Equipment, Petroleum Machinery Manufacturing, Agriculture Machinery, Textile Machinery, Food Machinery, Aerospace Industry, Automotive Industry, Shoemaking Industry, Woodwork Industry, Advertising Industry
- Cooling System：Water Cooling
- Applicable Material：Nonmetal
- Structure Type：Desktop
Base Info
- Model NO.：LM1325
- Laser Classification：CO2
- Model No.：Lm1325
- Laser Power：100W,130W,150W,180W,300W
- Driving System：Stepper Motor
- Transport Package：Plywood Box
- Specification：370*220*115cm
- Trademark：LASER MAX
- Origin：China
- HS Code：845611
- Production Capacity：3000sets,Month
Description
Model
LMR1325 laser engraving and cutting machine
Colour
Grayish and white
Working Table Size
1300mmm *2500mm
Laser Tube
Sealed CO2 glass Tube
Working Table
Blade platform (aluminum blade platform optional)
Laser Power
500W
Cutting Speed
0-100 mm/s
Engraving Speed
0-600mm/s
Resolution
±0.05mm/1000DPI
Minimum Letter
English 1×1mm (Chinese Characters 2*2mm)
Support Fils
BMP,HPGL,PLT,DST and AI
Interface
USB2.0
Software
Rd works
Computer system
Windows XP/win7/ win8/win10
Motor
57 Stepper Motor
Power Voltage
AC 110 or 220V±10%,50-60Hz
Power cable
European Type/China Type/America Type/UK Type
Working Environment
0-45ºC(temperature) 5-95%(humidity)
Position system
Red-light pointer
Cooling way
Water cooling and protection system
Packing Size
2850*1900*1070mm
Gross Weight
850KG
Cutting thickness
Please consult sales
Package
Standard plywood case for export
Warranty
All life free tech support, two year warranty, except consumables
Free accessories
Air Compressor/Water Pump/Air Pipe/Water Pipe/Software and Dongle/ English User Manual/USB Cable/Power Cable
Optional parts
Spare Focus lens
Spare Reflecting mirror
Spare Rotary for cylinder materials
Industrial Water Chiller
Product Details
Product ApplicationsApplication industry:
advertising, handicrafts, clothing leather, kitchenware, lighting and other industries.
Applicable materials:
Professional for cutting a variety of thin plates, die-cutting board quality cutting, can also cut PVC, density board, acrylic, ABS, wood and other non-metallic materials.
Product real shot
