Raycus Fiber Laser Source 300W 500W 750W 1000W 1500W 2000W 3000W 4000W 6000W 8000W 12000W15000wraycus Laser Source Raycus Fiber Laser Source

Shenzhen Dapeng Laser Technology Co., Ltd.
  • After-sales Service：24 Hours
  • Warranty：2 Years on Laser Source
  • Customized：Non-Customized
  • Standard Component：Standard Component
  • Type：Laser Source
  • Transport Package：Wooden Package

Base Info

  • Model NO.：RFL-C1000X
  • Trademark：Raycus
  • Origin：China Wuhan
  • Production Capacity：50set,Day

Description

ModelRFL-C3000Central wavelength(nm)1080±5Average output power: (W)3000Output power stability±1.5%Maximum modulation frequency:(kHz)5Red laserYesOutput connectorQBH(customizable)Output fiber core diameter(μm)50(customizable)Polarization stateRandomOutput fiber length(m)20(customizable)Beam quality5-7Iutput power(V AC)380±10%,Three Phase-four Wire ConnectControl modeRS232,ADPower adjustment range(%)10-100Polarization stateRandomDimensions (mm )900*447*521(handle included)Weight (kg )<80Working temperature(ºC )10-40Cooling methodWater cooling
It has the advantages of high electro-optical conversion efficiency, good beam quality, high energy density, wide modulation frequency, strong reliability, long life, and maintenance-free operation. It can be widely used in welding, precision cutting, cladding, surface treatment, 3D printing and other fields. Its optical fiber output characteristics make it easier to integrate with robots into flexible manufacturing equipment to meet the needs of three-dimensional processing.
